Panasonic TX-24MSW504 - Page 16

English
16
Connection terminals
AV in
Mini,1.0V[p-p](75Ω)
EARPHONE
Mini, 150mV rms ~ 250mV rms
HDMI 1/2 input
TYPE A Connectors
USB
USB2.0 DC 5V, Max.500 mA
Speaker Output
24-inch model
Audio output
6 W (3 W + 3 W)
32-inch model
Audio output
10 W (5 W + 5 W)
43-inch model
Audio output
16 W (8 W + 8 W)
Receiving systems/Band name
9 Systems
Systems Function
1 PAL B, G
2 PAL I
3 PAL D, K Reception of broadcast
4 NTSC 4.43
5 NTSC 3.58 Playback from Special
VCR's or DVD
6 PAL
7 PAL 60 Hz/5.5 MHz Playback from Special
Disc Players and Special
VCR's or DVD
8 PAL 60 Hz/6.0 MHz
9 PAL 60 Hz/6.5 MHz
Receiving channels (Analogue TV)
VHF BAND
2-12 (PAL)
0-12 (PAL B AUST.)
1-9 (PAL B N.Z.)
1-12 (PAL)
UHF BAND
21-69 (PAL G, H, I)
28-69 (PAL B AUST.)
13-57 (PAL D, K)
Digital TV
DVB-T/T2 Standard
Aerial input
VHF/UHF
Operating conditions
Temperature
0 °C - 45 °C
Humidity
20 % - 80 % RH (non-condensing)
Note
● Design and Specifications are subject to change
without notice. Mass and Dimensions shown are
approximate.
Built-in wireless LAN
Standard compliance and Frequency range
IEEE 802.11 a/b/g/n/ac
2.4~2.5GHz and 5.15~5.825GHz
Security
Support for WPA/WPA2
Built-in Bluetooth
Bluetooth V5.0
2.4~2.485GHz
Note
● Design and Specifications are subject to change
without notice. Mass and Dimensions shown are
approximate.
● For more product information, please visit EPREL:
https://eprel.ec.europa.eu.
EPREL registration number is available on
https://eprel.panasonic.eu/product.
