Panasonic TX-28PM11D - Page 22

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
CAPACITORS
FILMC459 ECQV1H474JL3 50V 470nF
CERAMICC551 ECKW3D221JBR 2kV 220pF
ELECTC567 ECA1EM471B 25V 470µF
FILMC581 ECWF4304JBP 400V 0.3µF
FILMC583 ECWH20472JVB 2KV 4.7nF
FILMC584 ECWH20472JVB 2KV 4.7nF
FILMC586 ECQF4123JZH 400V 12nF
FILMC587 ECQF4103JZH 400V 10nF
DIFFERENCES FOR MODEL TX--28PM11F
EXPLODED VIEW
BACK COVER 14 TKU0E0123
C.R.T. 15 W66MAF185X02
CABINET 16 TKY0E0136
D P.C.B. 17 TNP8ED020BE
DEGAUSS COIL 18 TLK8E05204
F.B.T. 19 ZTFN65013A
G P.C.B. 20 TNP8EG020AK
L P.C.B. 21 TNP8EL021AM
MODEL LABEL 22 TBM0E0290
MISCELLANEOUS COMPONENTS
SET FOOT (FRONT) . TBL8E014
CRT SUPPORT BRACKET R. TKK0E9507
CARTON . TPC0E44301
BOTTOM CUSHION . TPD0E0050
TOP CUSHION . TPD0E0051
INSTRUCTION BOOKS
GERMAN . TQB0E0061A-M
DUTCH . TQB0E0061B-M
FRENCH . TQB0E0061D-M
SPANISH . TQB0E0061E-M
SWEDISH . TQB0E0061F-M
NORWEGIAN . TQB0E0061G-M
FINNISH . TQB0E0061H-M
DANISH . TQB0E0061K-M
I.C.s
RGB OUTPUT IC351 TDA6101Q/N3
RGB OUTPUT IC361 TDA6101Q/N3
RGB OUTPUT IC371 TDA6101Q/N3
32K EAROM 24C32A10PI27IC1104 1500/1EF
COILS
COIL L581 ELHKLB061B
COIL L584 ELH5L7742
PFC COIL L804 ETQR42T027A
RESISTORS
S.M.CARBR357 ERJ6GEYJ271V 0.1W 5% 270 Ω
FUSIBLER370 ERQ1CJP1R2S 1W 5% 1.2 Ω
CARBONR458 ERDS1TJ270T 0.5W 5% 27 Ω
METALR460 ERG3FJ102H 3W 5% 1K Ω
FUSIBLER461 ERX2SJS1R2H 2W 5% 1R2 Ω
S.M.CARBR463 ERJ6GEYJ681V 0.1W 5% 680 Ω
METALR507 ERG3FJ820H 3W 5% 82 Ω
METALR553 ERX3SJS1R2H 3W 5% 1R2 Ω
METALR583 ERG3FJ561H 3W 5% 560 Ω
METALR703 343-22R7AY 10W 5% 2R7 Ω
CARBONR713 ERDS2TJ161T 0.25W 5% 160 Ω
CAPACITORS
FILMC459 ECQV1H474JL3 50V 470nF
CERAMICC551 ECKW3D221JBR 2kV 220pF
ELECTC567 ECA1EM471B 25V 470µF
FILMC581 ECWF4304JBP 400V 0.3µF
FILMC583 ECWH20472JVB 2KV 4.7nF
FILMC584 ECWH20472JVB 2KV 4.7nF
FILMC586 ECQF4123JZH 400V 12nF
FILMC587 ECQF4103JZH 400V 10nF
DIFFERENCES FOR MODEL TX--28PM11P
EXPLODED VIEW
BACK COVER 14 TKU0E0123
C.R.T. 15 W66MAF185X02
CABINET 16 TKY0E0136
D P.C.B. 17 TNP8ED020BE
DEGAUSS COIL 18 TLK8E05204
F.B.T. 19 ZTFN65013A
G P.C.B. 20 TNP8EG020AK
L P.C.B. 21 TNP8EL021AM
MODEL LABEL 22 TBM0E0291
MISCELLANEOUS COMPONENTS
SET FOOT (FRONT) . TBL8E014
CRT SUPPORT BRACKET R. TKK0E9507
CARTON . TPC0E44301
BOTTOM CUSHION . TPD0E0050
TOP CUSHION . TPD0E0051
INSTRUCTION BOOKS
BULGARIAN . TQB0E0062M-M
ROMANIAN . TQB0E0062N-M
POLISH . TQB0E0062P-M
HUNGARIAN . TQB0E0062Q-M
CZECH . TQB0E0062R-M
ENGLISH . TQB0E0062U-M
SLOVAKIAN . TQB0E0062W-M
I.C.s
RGB OUTPUT IC351 TDA6101Q/N3
RGB OUTPUT IC361 TDA6101Q/N3
RGB OUTPUT IC371 TDA6101Q/N3
32K EAROM 24C32A10PI27IC1104 1500/1EP
COILS
COIL L581 ELHKLB061B
COIL L584 ELH5L7742
PFC COIL L804 ETQR42T027A
RESISTORS
S.M.CARBR357 ERJ6GEYJ271V 0.1W 5% 270 Ω
FUSIBLER370 ERQ1CJP1R2S 1W 5% 1.2 Ω
CARBONR458 ERDS1TJ270T 0.5W 5% 27 Ω
METALR460 ERG3FJ102H 3W 5% 1K Ω
FUSIBLER461 ERX2SJS1R2H 2W 5% 1R2 Ω
S.M.CARBR463 ERJ6GEYJ681V 0.1W 5% 680 Ω
METALR507 ERG3FJ820H 3W 5% 82 Ω
METALR553 ERX3SJS1R2H 3W 5% 1R2 Ω
METALR583 ERG3FJ561H 3W 5% 560 Ω
METALR703 343-22R7AY 10W 5% 2R7 Ω
CARBONR713 ERDS2TJ161T 0.25W 5% 160 Ω
CAPACITORS
FILMC459 ECQV1H474JL3 50V 470nF
CERAMICC551 ECKW3D221JBR 2kV 220pF
ELECTC567 ECA1EM471B 25V 470µF
FILMC581 ECWF4304JBP 400V 0.3µF
FILMC583 ECWH20472JVB 2KV 4.7nF
FILMC584 ECWH20472JVB 2KV 4.7nF
FILMC586 ECQF4123JZH 400V 12nF
FILMC587 ECQF4103JZH 400V 10nF
22
