Panasonic TX-28PM11D - Page 24

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
C.R.T. 15 W76EPA11X74
CABINET 16 TKY0E0135
D P.C.B. 17 TNP8ED020BD
DEGAUSS COIL 18 TLK8E05203
F.B.T. 19 ZTFN65012A
G P.C.B. 20 TNP8EG020AD
L P.C.B. 21 TNP8EL021AL
MODEL LABEL 22 TBM0E0288
MISCELLANEOUS COMPONENTS
SET FEET . TBL8E017
CRT SUPPORT BRACKET L. TKK0E9508
CARTON . TPC0E43301
BOTTOM CUSHION . TPD0E0044-1
TOP CUSHION . TPD0E0045
SUB CUSHION . TPD0E1006
INSTRUCTION BOOKS
BULGARIAN . TQB0E0062M-M
ROMANIAN . TQB0E0062N-M
POLISH . TQB0E0062P-M
HUNGARIAN . TQB0E0062Q-M
CZECH . TQB0E0062R-M
ENGLISH . TQB0E0062U-M
SLOVAKIAN . TQB0E0062W-M
I.C.s
RGB OUTPUT IC351 TDA6111Q/N4
RGB OUTPUT IC361 TDA6111Q/N4
RGB OUTPUT IC371 TDA6111Q/N4
32K EAROM 24C32A10PI27IC1104 1500/1FP
COILS
COILL557 EXCELDR35V
COILL558 EXCELSA35B
COIL L582 ELC18B221G
COIL L584 ELH5L7717
PFC COIL L804 R39264
RESISTORS
S.M.CARBR357 ERJ6GEYJ681V 0.1W 5% 680 Ω
FUSIBLER370 ERQ2CJP1R2S 2W 5% 1R2 Ω
CARBONR458 ERDS1TJ1R0T 0.5W 5% 1 Ω
METALR460 ERG3SJS271H 3W 5% 270 Ω
METALR461 ERX2SJS1R0H 2W 5% 1 Ω
S.M.CARBR463 ERJ6GEYJ621V .125W 5% 620 Ω
METALR507 ERG3FJ680H 3W 5% 68 Ω
METALR553 ERX3SJSR68H 3W 5% R68 Ω
METALR703 343-23R3AY 10W 5% 3R3 Ω
CARBONR713 ERDS2TJ301T 0.25W 5% 300 Ω
CAPACITORS
S.M.CAPC453 ECJ2FB1H104K 50V 100nF
S.M.CAPC454 ECJ2FB1H104K 50V 100nF
FILMC459 ECQB1224KFW 100V 220nF
CERAMICC551 ECKW3D391JBR 2kV 390pF
ELECTC567 ECA1EM222E 25V 2200µF
FILMC581 ECWF4824JBB 400V 820nF
FILMC582 ECWF4514JBB 400V 510nF
FILMC583 ECWH20562JVB 2KV 5.6nF
FILMC584 ECWH20562JVB 2KV 5.6nF
FILM C587 ECQF4273JZH 400V 27nF
FILMC588 ECWF4824JBB 400V 820nF
24
