Panasonic TX-32LX85F - Replacement Parts List

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type number to your order.
Replacement Parts List
Important Safety Notice
The marking (RTL) indicates that the Retention Time is Limited for this item. After the
discontinuation of this assembly in production, the item will continue to be available for
a specific period of time. The retention period of availability is dependent on the type of
assembly, and in accordance with the laws governing part and product retention. After
the end of this period, the assembly will no longer be available.
RTL (Retention Time Limited)
Note:
X
The marking (X) indicates that board should be exchanged for service.
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COMMON PARTS
EXPLODED VIEW
SPEAKER 1 EAS16S09A
TUNER 2 ENG37E09KF
CONTROL PANEL 3 K0RB00500028
REMOTE CONTROL 4 N2QAYB000241
POWER BUTTON 5 TBX0E84900
CONNECTOR COVER 6 TKP0E16001
REAR AV BRACKET 7 TKP0E30801
HDMI/SD BRACKET 8 TKP0E32501
LCD BRACKET 9 TKZ0E9164
VESA METAL 10 TKZ0E9575
G P.C.B. 11 TNP8EGL91AA
K P.C.B. 12 TNP8EKL92AA
P P.C.B. 13 TNP8EPL90AA
V P.C.B. 14 TNP8EVL92AB
MISCELLANEOUS COMPONENTS
FERRITE CORE . J0KF00000018
FERRITE CORE . J0KG00000100
BATTERY . R6RC/2P
SIDE AV LABEL . TBM0E1204
HDMI/REAR LABEL . TBM0E1463
SD LABEL . TBM0E1557
HDMI/SIDE LABEL . TBM0E9005
REAR AV LABEL . TBM0E9015
SPRING . TES0E105-1
SCREW . THTF012J
FELT . TMK0E089
FELT . TMK0E090
TAB-RELEASE CABLE. TMM8E18048
CLEANING CLOTH . TPEX020
SCREW . XTB4+15JFJK
SCREW . XTS3+8JFJ
SCREW . XTV3+10JFJK
SCREW . XTW3+12TFJ
SCREW .XYN3+J8FJ
SCREW . XYN4+C12FJ
SCREW . XYN4+F10FJ
I.C.s
MAIN PS CONTROL IC801 C0DABZZ00012
MAIN PS CONTROL IC802 C5HAZZZ00012
SWITCHING REGULATORIC803 C0DABYY00015
REGULATOR IC851 C0DBEMC00044
REGULATOR IC853 C0DBEMC00044
DC/DC CONVERTER IC854 N0BH2GE00001
IC IC1000 C1ZBZ0003577
MICRO_GENX5 IC1100 MNZSFG3GP53
EEPROM GENX IC1101 24GLP23GENX
RESET IC IC1104 C0EBM0000026
REGULATOR IC2008 C0CBCBE00001
AUDIO AMPLIFIER IC2012 C1BB00000947
REGULATOR IC2013 C0DBGYY00281
AUDIO PROCESSOR IC2106 C1AB00002909
1.8V REGULATOR IC2107 C0DBFFD00003
AUDIO AMPLIFIER IC2301 C1AB00002875
REGULATOR IC2902 C0DBGYY00281
AUDIO VIDEO SWITCHIC3001 C1AB00002855
HQ1L_IC IC4200 C1AB00002727
DDR SDRAM IC4201 C3ABQJ000051
REGULATOR IC4202 C0DBAMH00018
2.5V REGULATOR IC4203 C0DBEHG00006
REGULATOR IC4204 C0CBCBC00190
REGULATOR IC4205 C0CBCAC00269
REGULATOR IC4206 C0CBCAC00269
LVDS TRANSMITTER IC4207 C0JBCZ000558
REGULATOR IC4208 C0CBCBD00043
EEPROM HQ1L IC4209 24GLP23HQ1L
AD VIDEO DECODER IC4510 C1AB00002966
REGULATOR IC4511 C0CBCBE00001
REGULATOR IC4512 C0DBGYY00477
REGULATOR IC4513 C0DBGYY00477
IC SWITCH IC4514 C0JBAZ002301
IC SWITCH IC4515 C0JBAZ002301
EEPROM EDID IC4700 24GLP23EDID3
DC/DC CONVERTER IC5600 C0DBAYY00273
DC/DC CONVERTER IC5601 C0DBAYY00274
REGULATOR IC5602 C0DBEYY00083
REGULATOR IC5603 C0DBAJB00004
IC OVP IC5604 C1ZBZ0003725
IC FOR POWER SUPPLYIC5605 C0DBEYY00084
RESET IC IC5660 C0EBM0000026
PEAKS LITE 2 IC8001 MN2WS0047
DDR SDRAM IC8002 C3ABRY000015
DDR SDRAM IC8003 C3ABRY000015
CLOCK GENERATOR IC8004 C0ZBZ0001567
FLASH MEMORY IC8554 TVR0E001-3
PHOTO COUPLER PC801 B3PAA0000363
PHOTO COUPLER PC802 B3PAA0000363
PHOTO COUPLER PC803 B3PAA0000363
LED RECEIVER RM2501 PNA4701M05TV
PHOTO IC DIODE SN2551 B3JB00000046
23
RTL
RTL
RTL
RTL
