English
7
Accessories
Standard accessories
Remote Control
(p. 17)
N2QAYB001010
Pedestal
(p. 7)
Cable tie (2)
(p. 16)
Batteries (2)
R6
(p. 18)
Operating Instructions
Pan European Guarantee Card
Accessories may not be placed all together. Take care
not to throw them away unintentionally.
Assembling / Removing the pedestal
Assembly screw (4)
M5 × 14
Assembly screw (4)
M4 × 12
Bracket
Bracket
Base
1
Base
2
Cover (2)
Preparations
Take out the pedestal and the TV from the packing case
and put the TV onto a work table with the screen panel
down on the clean and soft cloth (blanket, etc.)
Use a flat and firm table bigger than the TV.
Do not hold the screen panel part.
Make sure not to scratch or break the TV.
Assembling the pedestal
40-inch model
Only 1 method can be selected to assemble the
pedestal.
50-inch model
58-inch model
Select a method to assemble the pedestal from the
following 2 styles.
To Next Page
