Panasonic TX-55HZ1500B

English
26
Specifications
 TV
Model No.
55-inch model
:
TX-55HZ1500B
65-inch model
:
TX-65HZ1500B
Dimensions (W × H × D)
55-inch model
1 228 mm × 772 mm × 350 mm (With Pedestal)
1 228 mm × 750 mm × 58 mm (TV only)
65-inch model
1 449 mm × 896 mm × 350 mm (With Pedestal)
1 449 mm × 874 mm × 58 mm (TV only)
Mass
55-inch model
30 kg Net (With Pedestal)
25 kg Net (TV only)
65-inch model
36 kg Net (With Pedestal)
31 kg Net (TV only)
Power source
AC 220-240 V, 50 / 60 Hz
Panel
OLED panel
Sound
Speaker output
80 W (15 W × 4 + 20 W × 1)
Headphones / Subwoofer
3.5 mm stereo mini jack × 1
Connection terminals
AV input
VIDEO
1.0 V[p-p] (75 :)
AUDIO L - R
0.5 V[rms]
HDMI 1 / 2 / 3 / 4 input
TYPE A Connectors
HDMI1 / 3 / 4:
4K, Content Type, Deep Colour, x.v.Colour™
HDMI2:
4K, Content Type, eARC (Enhanced Audio
Return Channel) / ARC (Audio Return Channel),
Deep Colour, x.v.Colour™

This TV supports “HDAVI Control 5” function.
Card slot
Common Interface slot (complies with CI Plus) × 1
ETHERNET
RJ45, IEEE802.3 10BASE-T / 100BASE-TX
USB 1 / 2 / 3
USB 1: DC
5 V, Max. 900 mA [SuperSpeed
USB (USB 3.0)]
USB 2 / 3: DC 5 V, Max. 500 mA [Hi-Speed
USB (USB 2.0)]
DIGITAL AUDIO OUT
PCM / Dolby Audio, Fibre optic
Receiving systems / Band name
Satellite
DVB-S / S2
Receiver IF frequency range - 950 MHz to 2150 MHz
Not available for DiSEqC control
Digital
DVB-T / T2
Channel coverage: UHF / VHF / cable
Analogue
PAL I
Channel coverage: UHF
PAL I
Channel coverage: UHF / VHF / Cable
PAL 525 / 60 (VCR, DVD player and recorder)
M.NTSC (VCR)
NTSC (AV input only)
Satellite dish input
Female F-type 75 : × 2
Aerial input
UHF
VHF / UHF
Operating conditions
Temperature
0 °C - 35 °C
Humidity
20 % - 80 % RH (non-condensing)
