English
8
Insert the pedestal at a slight angle into the TV as
shown.
(View from the side)
2
3
B
Removing the pedestal from the TV
Be sure to remove the pedestal in the following way
when using the wall-hanging bracket or repacking the
TV.
1 Remove the assembly screws
from the TV.
2 Lift up the TV at a slight angle from the pedestal as
shown.
(View from the side)
3 Remove the assembly screws
from the bracket.
To Next Page
