A-BOARD TNP4G510 - BOTTOM
6
5
4
2 1
A
B
C
D
3
IC’S
Q2002 1D
IC3001 2B
Q3102 1A
IC5416 4B
Q3103 1A
IC8100 5D
Q4150 2C
IC8403 6C
Q4151 3D
IC8700 2D
Q4152 3D
IC8701 1D
Q4153 2C
IC8702 4B
Q4600 3B
IC8706 4B
Q4604 4B
IC8900 6C
Q4971 6D
IC8901 3A
Q4972 6D
Q4973 5B
TRAN’S
Q4974 3B
Q2001 1D
