Panasonic TX32DSW504 - Page 9

English
9
49-inch model 55-inch model
Assembly screw (4)
M5 × 15
Assembly screw (4)
M4 × 12
Bracket (2)
Base
49-inch model
55-inch model
 Assembling the pedestal
A
C
D
1
2
B
3
Removing the pedestal from the TV
Be sure to remove the pedestal in the following way
when using the wall-hanging bracket or repacking the
TV.
1 Remove the assembly screws
from the TV.
2 Pull out the pedestal from the TV.
3 Remove the assembly screws
from the bracket.
