Specifications
TX-L32D25B TX-L37D25B TX-L42D25B
Power Source AC 220-240 V, 50 / 60 Hz
Rated Power Consumption 136 W 147 W 152 W
Standby Power Consumption
0.30 W
36.00 W (With monitor out recording)
Display
panel
Aspect Ratio 16:9
Visible screen size
80 cm (diagonal)
698 mm (W) × 393 mm (H)
94 cm (diagonal)
819 mm (W) × 461 mm (H)
107 cm (diagonal)
930 mm (W) × 523 mm (H)
Number of pixels 2,073,600 (1,920 (W) × 1,080 (H))
Sound
Speaker 140 mm × 35 mm × 2 pcs, 8
Ω
Audio Output 20 W (10 W + 10 W), 10% THD
Headphones M3 (3.5 mm) stereo mini Jack × 1
PC signals
VGA, SVGA, WVGA, XGA
SXGA, WXGA ······ (compressed)
Horizontal scanning frequency 31 - 69 kHz
Vertical scanning frequency 59 - 86 Hz
Receiving Systems /
Band name
DVB-S / S2
(
freesat
Other Sat.
)
: freesat services via Satellite dish input.
Receiver frequency range
- 950 MHz to 2,150 MHz
LNB Power and Polarisation - Vertical: +13 V
Horizontal: +18 V
Current: Max. 500 mA (overload protection)
22 kHz Tone - Frequency: 22 kHz ± 2 kHz
Amplitude: 0.6 V ± 0.2 V
Symbol Rate - Max. 30 MS/s
FEC Mode - 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
Demodulation - QPSK, 8PSK
Not available for DiSEqC control.
DVB-T / T2 : Digital terrestrial services via UHF aerial input.
PAL I : UHF E21-68
PAL 525/60 : Playback of NTSC tape from some PAL Video recorders (VCR) or
NTSC disc playback from DVD player and recorder.
M.NTSC : Playback from M.NTSC Video recorders (VCR).
NTSC (AV input only)
: Playback from NTSC Video recorders (VCR).
Satellite dish input Female F-type 75
Ω
Aerial input UHF
Operating Conditions
Temperature : 0 °C - 35 °C
Humidity : 20 % - 80 % RH (non-condensing)
Connection Terminals
AV1 (SCART terminal) 21 Pin terminal (Audio/Video in, Audio/Video out, RGB in, Q-Link)
AV2 (SCART terminal) 21 Pin terminal (Audio/Video in, Audio/Video out, RGB in, S-Video in, Q-Link)
AV3
VIDEO RCA PIN Type × 1 1.0 V[p-p] (75 Ω)
AUDIO L - R
RCA PIN Type × 2 0.5 V[rms]
COMPONENT
VIDEO
Y 1.0 V[p-p] (including synchronization)
P
B, PR ±0.35 V[p-p]
AUDIO L - R
RCA PIN Type × 2 0.5 V[rms]
Others
HDMI
1 / 2 / 3 / 4
TYPE A Connectors
HDMI1 / 3 / 4 : HDMI (Version 1.4 with Content Type)
and HDMI (Version 1.3a with Deep Colour)
HDMI2 : HDMI (Version 1.4 with Content Type, Audio Return Channel)
and HDMI (Version 1.3a with Deep Colour)
This TV supports “HDAVI Control 5” function.
●
PC
HIGH-DENSITY D-SUB 15PIN R,G,B/0.7 V[p-p] (75 Ω)
HD, VD/TTL Level 2.0 - 5.0 V[p-p] (high impedance)
Card slot
SD Card slot × 1
Common Interface slot × 1
ETHERNET
RJ45, IEEE802.3 10BASE-T / 100BASE-TX
USB 1 / 2
USB2.0 DC 5 V, Max 500 mA
For
● available USB devices p. 98
Output
AUDIO L - R
RCA PIN Type × 2 0.5 V[rms] (high impedance)
DIGITAL
AUDIO OUT
PCM / Dolby Digital, Fiber optic
Dimensions
(W × H × D)
With Pedestal
795 mm × 564 mm × 217 mm 917 mm × 632 mm × 287 mm
1,032 mm × 697 mm × 329 mm
TV only
795 mm × 521 mm × 77 mm
(With speaker part)
795 mm × 521 mm × 45 mm
(Without speaker part)
917 mm × 590 mm × 77 mm
(With speaker part)
917 mm × 590 mm × 45 mm
(Without speaker part)
1,032 mm × 655 mm × 77 mm
(With speaker part)
1,032 mm × 655 mm × 39 mm
(Without speaker part)
Mass
14.0 k
Net (With Pedestal)
12.0 k
Net (TV only)
17.5 k
Net (With Pedestal)
14.5 k
Net (TV only)
21.5 k
Net (With Pedestal)
18.5 k
Net (TV only)
Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate.●
This equipment complies with the EMC standards listed below. ●
EN55013, EN61000-3-2, EN61000-3-3, EN55020, EN55022, EN55024
