When connecting RAC Multi outdoor unit (Refrigerant type : R32), see the follow section as well.
Names of Parts
RAC MULTI OUTDOOR UNIT
2 ROOM MULTI
(Type 35, 41, 50)
3 ROOM MULTI
(Type 52, 68)
4 ROOM MULTI
(Type 68)
4 ROOM MULTI
(Type 80)
5 ROOM MULTI
(Type 90)
Air intake
Air outlet
Air intake
Air intake
Air outletAir outlet
Europe
Multi Outdoor unit type 35 41 50
2 Room Multi 1-phase CU-2Z35TBE CU-2Z41TBE CU-2Z50TBE
Multi Outdoor unit type 52 68
3 Room Multi 1-phase CU-3Z52TBE CU-3Z68TBE
Multi Outdoor unit type 68 80
4 Room Multi 1-phase CU-4Z68TBE CU-4Z80TBE
Multi Outdoor unit type 90
5 Room Multi 1-phase CU-5Z90TBE
Oceania
Multi Outdoor unit type 52
2 Room Multi 1-phase CU-2Z52VBR
Multi Outdoor unit type 54
3 Room Multi 1-phase CU-3Z54VBR
Multi Outdoor unit type 71 80
4 Room Multi 1-phase CU-4Z71VBR CU-4Z80VBR
Multi Outdoor unit type 100
5 Room Multi 1-phase CU-5Z100VBR
Connectable RAC Multi outdoor unit lineup
