Panasonic U-100PZ2E5 - Multi Split Outdoor Unit Specifications

21
Supplement

Specications
Multi Split Outdoor Unit
Model CU-2Z35TBE CU-2Z41TBE CU-2Z50TBE CU-3Z52TBE
Standard Indoor Unit
Combination
(wall mounted) (Capacity)
(1.6 kW + 2.0 kW) (1.6 kW + 2.5 kW) (2.5 kW + 2.5 kW)
(1.6 kW + 1.6 kW
+ 2.0 kW)
Power Source Single phase, 230 V, 50 Hz
Cooling capacity
kW
3.50
(1.50 - 4.50)
4.10
(1.50 - 5.20)
5.00
(1.50 - 5.40)
5.20
(1.80 - 7.30)
Heating capacity
kW
4.20
(1.10 - 5.60)
4.60
(1.10 - 7.00)
5.60
(1.10 - 7.20)
6.80
(1.60 - 8.30)
Noise
Level
Sound pressure level
(acc. to JIS C 9612
[<70 dB(A)]);
Conditions: 1 m distance
in standard heating mode
dB(A)
COOL
HEAT
48
50
48
50
50
52
47
48
Sound Power Level
dB(A)
COOL
HEAT
63
65
63
65
65
67
61
62
Dimensions
Height
Width
Depth
mm
mm
mm
619
824 (+70)
299
619
824 (+70)
299
619
824 (+70)
299
795
875 (+95)
320
Product Weight
kg
39 39 39 71
Model CU-3Z68TBE CU-4Z68TBE CU-4Z80TBE CU-5Z90TBE
Standard Indoor Unit
Combination
(wall mounted) (Capacity)
(1.6 kW + 2.0 kW
+ 3.5 kW)
(1.6 kW + 1.6 kW
+
1.6 kW + 2.0 kW)
(2.0 kW + 2.0 kW
+
2.0 kW + 2.0 kW)
(1.6 kW + 1.6 kW
+
1.6 kW + 1.6 kW +
2.5 kW)
Power Source Single phase, 230 V, 50 Hz
Cooling capacity
kW
6.80
(1.90 - 8.00)
6.80
(1.90 - 8.80)
8.00
(3.00 - 9.20)
9.00
(2.90 - 11.50)
Heating capacity
kW
8.50
(3.30 - 10.40)
8.50
(3.00 - 10.60)
9.40
(4.20 - 10.60)
10.40
(3.40 - 14.50)
Noise
Level
Sound pressure level
(acc. to JIS C 9612
[<70 dB(A)]);
Conditions: 1 m distance
in standard heating mode
dB(A)
COOL
HEAT
51
52
49
50
51
52
53
54
Sound Power Level
dB(A)
COOL
HEAT
65
66
63
64
67
68
69
70
Dimensions
Height
Width
Depth
mm
mm
mm
795
875 (+95)
320
795
875 (+95)
320
999
940
340
999
940
340
Product Weight
kg
71 72 80 81
•Forcompleteproductspecication,pleaserefertocatalog.
•Standbypowerconsumption≤12.0W(whenswitchedOFFbyremotecontrol,exceptunderself-protectioncontrol).
