Aquarea air / water heat pump – design handbook 07 / 2014
Products, functions and technical data
Bi-Bloc system
Outdoor unit
540
622
330 298
23
124
846 69
160
29837
2
3
1
Outdoor unit
Dimensional drawing
for outdoor unit with
one fan (3 and 5 kW)
1
Front view
2
Side view
3
Bottom view
Dimensions of outdoor unit with one fan (3 and 5 kW) in mm.
The air ow is depicted by arrows.
