PANASTEREO SP23 – Alignment with SMART MOD VI – Analog Matrix
38
33. EQUALISE REAR LEFT SURROUND
CHANNEL
Remove the Rear Equaliser from the SP23
and connect it via the extender card and cable.
Adjust the left equaliser controls for a
frequency response in accordance with the
standard ISO surround channel response
curve.
34. SET REAR LEFT SURROUND SPL
LEVEL TO 88dBC
Adjust the Rear Left Surround Output trimmer
(CSL) on the SP23 for 88dBC in the
auditorium.
35. TURN OFF LEFT REAR AMPLIFIER
AND TURN ON RIGHT REAR
AMPLIFIER
Switch off or disconnect the rear left-surround
amplifier and switch on or connect the rear
right surround amplifier.
36. COARSE SET RIGHT REAR
SURROUND SPL LEVEL to 85dBC
Adjust the Rear Right Surround Output
trimmer (CSR) for approximately 85dBC SPL
in the auditorium.
37. EQUALISE REAR RIGHT SURROUND
CHANNEL
Adjust the right equaliser controls for a
frequency response in accordance with the
standard ISO surround channel response
curve.
38. SET REAR RIGHT SURROUND SPL
LEVEL TO 88dBC
Replace the Rear Equaliser card and adjust
the Rear Right Surround Output trimmer
(CSR) on the SP23 for 88dBC in the
auditorium.
39. TURN ON REAR LEFT AMPLIFIER
Switch on or re-connect the rear left surround
amplifier.
40. RE-CONNECT AUTOMATION CABLE
Re-connect the automation cable to the SP23.
41. TURN OFF PINK NOISE
Set SW1-8 up and all SW2 switches up
42. END OF PROCEDURE
The system is now ready to use.
