PANASTEREO SP23 – Installation.
6
CONNECTING THE INPUTS TO THE SP23.
SOUND PROCESSOR WITH UNBALANCED OUTPUTS (DOLBY, SMART, ULTRA STEREO)
Disconnect the left surround and right surround connections at the sound processor outputs.
Use two-core shielded audio cable to connect the left and right surround outputs from the sound
processor to the left and right inputs of the SP23.
Connect the “+” terminal from each sound processor output to the “+” terminal of each corresponding
SP23 input.
Connect the ground terminal of each processor output to the “-“ terminal of each corresponding SP23
input.
Connect the cable shield to the “E” terminal of each SP23 input only. Do not connect the shields at
the sound processor.
SOUND PROCESSOR WITH BALANCED OUTPUTS (PANASTEREO)
Disconnect the left surround and right surround connections at the sound processor outputs.
Use two-core shielded audio cable to connect the left and right surround outputs from the sound
processor to the left and right inputs of the SP23.
Connect the “+” terminal from each sound processor output to the “+” terminal of each corresponding
SP23 input.
Connect the “-“ terminal of each processor output to the “-“ terminal of each corresponding SP23
input.
Connect the cable shield to the “E” terminal of each SP23 input only. Do not connect the shields at
the sound processor.
AUTOMATION CABLE
The SP23 must be connected to the cinema processor or digital processor automation connector.
The SP23 D25 automation connector is pin compatible with Panastereo CSP42000, CSP1200, Dolby
CP65 and CP500 processors.
A pre-made 25 way ribbon cable is supplied with the SP23 for the above processors.
