8 Technical data P3
8.1 Device classification
According to the Medical Devices Directive
Risk Class I
Protection against electrical hazards
Class II
Degree of protection against direct and indirect contacts
Type B
Use in oxygen-rich environments
No protection
Employment conditions
Device for continuous operation
8.2 Technical Specifications
MODEL
P3
USER MAXIMUM WEIGHT
120 Kg
1
MAXIMUM TRAINABLE WEIGHT (INCLUDING
USER AND ACCESSORIES, AND PANDHORA P3)
130 Kg
GRADEABILITY
Up to 15%
2
DIMENSIONS
Max height: 126 cm
Max width 52 cm
Max depth 61 cm
WEIGHT
Total 12,5 kg
INSTALLATION CONDITIONS ON THE
WHEELCHAIR
Starting from the seat width of 34 cm
FULL SPEED
Up to 6 km / h
3
STEERING WHEEL TYPE
reinforced aluminium rim wheel
WHEEL DIAMETER
14”
TIRE TYPE
Mountain Bike
INFLATION PRESSURE
Max 250 kPa
TREAD WIDTH
2,125 cm (mountain bike version)
DISC BRAKE
Diameter 160 cm
Li-on BATTERY
48 V 16Ah 768 Wh
BATTERY WEIGHT
2,5 kg
POWER SUPPLY
54,6 V
4A
ELECTRIC MOTOR POWER
From 500 to 1000 W
AUTONOMY
Up to 60 km (with full charge)
4
8.3 Environmental Conditions Of Use
Temperature
Min -10°C –max + 40°C
Humidity
Max 90% without condensation
Atmospheric pressure
800-1060 hPa
1
In any case, it is absolutely necessary to observe and respect the maximum capacity of the wheelchair, which
is indicated by the manufacturer.
2
In any case, the wheelchair requirements as indicated by the manufacturer, must be observed and respected.
3
The maximum speed allowed is 6 km/h on the areas and 12 km/h on the cycle paths. In private areas and
roads, the speed can also be higher than 12 km / h.
4
The data refer to a charged 16 A battery, flat route and user weight about 75 kg
