14 15
SPECIFICATIONS
Parameter
Value
min max
Tracker operation voltage
3 V 5,5 V
Current consumption in the Sleep/
Transmission mode
<3 A <100 mA
Battery/Amount AAA / 3 pcs.
GSM-modem Telit GE866-QUAD
SIM-card type micro-SIM
2.4 GHz transmission protocol
Bluetooth 4.2
LowEnergy
GPS/GLONASS module Simcom SIM33ELA
Operating temperature range
(depends on the batteries
- 40 ° + 85 °
Dimensions 52x42x17,5 mm
WARRANTY OBLIGATIONS
Manufacturer guarantees correct operation of the service-
security system if exploitation, installation, storage and
transportation conditions described in this manual were met.
The system should only be used according to the manual.
Parts malfunctioning during warranty period on the fault of the
manufacturer should be repaired or replaced by the installation
center of the manufacturer or by certied service center.
IT IS RECOMMENDED TO USE LITHIUM (LI-FES2) BATARIES
ESPECIALY AT LOW TEMPERATURES. ALKALINE BATARIES
ARE ALSO ALLOWED; DO NOT USE REGULAR ZINC-CARBON
BATTERIES.
«File manager» - you can upload the rmware from the phone’s
memory. (the rmware is available on pandorainfo.com).
«Internet» - you can upload the rmware from the internet
server.
REPLACING OR RECHARGING THE BATTARIES
When replacing or recharging the batteries, it is necessary to
carefully perform the following sequence of actions:
1. Open the cover of the device by bending two side latches.
2. Extract discharged batteries.
3. Replace or recharge the batteries.
4. Insert the batteries keeping in mind the correct polarity.
5. Close the cover keeping the location of the side opening for
the built-in microphone.
