PC-1000/Laser 1000 Components
Cephalometric
Exposure Time Chart
90 kVP 10 mA
Rare Earth Screens And Film
Seconds
Patient Size:
Small Child
Large Child
Average Adult
Large Adult
Lateral
AP-PA
.5-1.0
.6-1.5
.8-2.0
1.0-2.5
.8-1.5
1.0-2.5
1.5-3.5
2.5-4.0
LASER 1000
Panoramic Corporation
®
PC-1000
Mid-Sagittal to Film Scale
Cephalostat Locking Knob
Suggested Settings Decal
Cephalostat Arm
Ear Posts
Nasion Support
Ear Rings
Ear Rods
Film Cassette
Horizontal Locking Knob
Vertical Locking Knob
Laser Switch
Collimator Lever
