Panther Foxy Pro - Quick Guide FOXY PRO

Instruction Manual
FOXY PRO
PASSION OF MOVEMENT www.panther.tv6
6. Quick Guide FOXY PRO
265 kg / 585 lbs
5,8m / 19ft.
3
250 kg / 550 lbs
2,45m/ 8ft.
7,3m / 24ft.
4
170 kg / 375 lbs
2,45m/ 8ft.
max. Height/Höhe:
6,1m(20ft.)
max. Height/Höhe:
7,3m(24ft.)
Front side / Vordere Seite:
Optional High rig
(remote only)
+ 80 cm / + 3 ft.
+ 1 m / + 3.5 ft.
2,45m / 8ft.
Rear side / Hintere Seite:
2,15m / 7ft.
1,85m / 6ft.
Quick Information
Schnellinformation
Please look into operating manual
for further information!
Bitte beachten Sie die Betriebsanleitung
für weitere Informationen!
Platform Versions:
Foxy PRO
Foxy PRO
Crane System:
265 kg / 585 lbs
2,8m / 9ft.
1
2,45m/ 8ft.
16
150 kg / 330 lbs
4,3m / 14ft.
2
2,45m/ 8ft.
16
max. Height/Höhe:
3,7m(12ft.)
max. Height/Höhe:
4,9m(16ft.)
Trapezoid / Trapez:
1,8 m / 6 ft.
2,2 m / 7 ft.
2,9 m / 9.5 ft.
Standard Trapezoid
(all versions)
1,8 m / 6 ft.
2,5 m / 8 ft.
optional Trapezoid compact
(up to version 6)
2,2 m / 7 ft.
4,3m / 14ft.
2.1
2,45m/ 8ft.
30
1 Panther counterweight / Gegengewicht = 17kg (37.5lbs)
39
4
39
4
39
4
Necessary number of Panther
counterweights in additional bucket
(e.g. 4 pcs.)
Necessary number of Panther
counterweights in bucket (e.g. 39
pcs.) for max. payload.
Special
length,
versions
and
accessories
on
request!
Note:
The measurements
and weights may differ
up to 2% due to
production tolerances.
Hinweis:
Die Masse u.
Gewichte kˆnnen
aufgrund
Fertigungstoleranzen
um 2% abweichen.
max. Height/Höhe:
4,9m(16ft.)
Foxy PRO
39
4
39
4
39
4
39
4
39
4
5,7m / 18.5ft.
3
80 kg/ 176lbs.
2,45m/ 8ft.
16
4,2m / 13.5ft.
2
80 kg/ 176lbs.
2,45m/ 8ft.
9
2,7m / 8.5ft.
1
80 kg/ 176lbs.
2,45m/ 8ft.
4
10,2m / 33.5ft.
6
80 kg/ 176lbs.
2,45m/ 8ft.
8,7m / 28,5ft.
5
80 kg/ 176lbs.
2,45m/ 8ft.
30
7,2m / 23.5ft.
4
80 kg/ 176lbs.
2,45m/ 8ft.
24
5,7m / 18.5ft.
3.1
80 kg/ 176lbs.
2,45m/ 8ft.
18
13,2m / 43.5ft., with High Rig 14m/46ft.
8
25 kg/ 55 lbs.
2,45m/ 8ft.
12,6m / 41.5ft., with High Rig 13,4m/44ft.
8.1
30 kg/ 65 lbs.
2,45m/ 8ft.
11,7m / 38.5ft.
7
50 kg/ 110 lbs.
2,45m/ 8ft.
11,1m / 36.5ft.
7.1
55 kg/ 120 lbs.
2,45m/ 8ft.
Remote Versions:
max.
Height/
Höhe:
12,3m
(40.5ft.)
max.
Height/
Höhe:
11,8m(39ft.)
max.
Height/Höhe:
11,1m(36.5ft.)
max. Height/Höhe:
10,5m(34.6ft.)
max. Height/Höhe:
9,8m(32.3ft.)
max. Height/Höhe:
8,6m(28.3ft.)
max. Height/Höhe:
7,4m(24.3ft.)
max. Height/Höhe:
6,1m(20ft.)
max. Height/Höhe:
6,1m(20ft.)
max. Height/Höhe:
4,9m(16ft.)
max. Height/Höhe:
3,7m(12ft.)
4,2m / 13.5ft.
2.1
80 kg/ 176lbs.
2,45m/ 8ft.
max. Height/Höhe:
4,9m(16ft.)
