2.5A 100/115/127/230Vac 50/60Hz
Main Fuse
Inlet Socket
Live - 2.5A
Neutral – 2.5A
Power Cord
Connector: country specific
Usage: Indoor
Only Altitude: 2000M
Transient Overvoltage: Category II
Environmental Specifications
Operating temperature: 0°C to 40°C (32°F to 104°F)
Design and specifications subject to change without notice.
If the equipment is used in a manner not specified by X-Rite, the protection provided by the
equipment may be impaired.
• ALWAYS UNPLUG THE UNIT BEFORE CHANGING THE VOLTAGE SELECTOR OR FUSE.
• CAUTION! THIS UNIT MUST BE EARTHED. DO NOT connect to an ungrounded outlet. DO NOT use
with 2-wire extension cords or adaptors.
• CHECK VOLTAGE SETTING PRIOR TO PLUGING IN THE UNIT. Applying the incorrect voltage may
cause the fuses to blow. Contact your local X-Rite representative for replacement fuses and follow
the fuse replacement procedure in this manual.
• USE ONLY A PROPER POWER SOURCE: Use the proper power source for this unit. Consult the
power label on the back of the unit for this information. Operation with a power source not
specified on the power label may result in inaccurate lighting conditions, damage to the
equipment, and possible personal injury.
Applying Power to the Assembled Unit
1. The mains inlet socket and power switch is located on the rear of the cabinet.
