Attach the Pivot Arm Reinforcement Plate (29) onto the Rear U-Frame (2) and with one Hex Head
Bolt (38), Lock Nut (15), and two Washers (13). Repeat above same step to attach the other Pivot
Arm Reinforcement Plate (29) onto the Rear U-Frame (2).
14
