Testing the NV35M
Perform a Walk-Test to test successful installation: Walk slowly across the
far end of the detection range. Ensure detection.
Walk test mode lasts 5 minutes after the tamper screw is closed.
Beam Pattern
PET Mode
SHARP Mode
Top View
LED Display
Technical Specifications
Notification
Changes or modifications to this equipment not expressly approved by the
party responsible for compliance (Paradox Security Systems Ltd.) could
void the user’s authority to operate the equipment.
Warranty
The Limited Warranty Statement found on the website www.paradox.com/
terms.
Your use of the Paradox product signifies your acceptance of these terms
and conditions.
Patents
The following US patents may apply 5,886,632 and 6,215,399, Other
Canadian and international patents may apply.
Printed in Canada 05/2015.
Feature LED Status Indicator
Tamper open Green: ON for 0.3 seconds every 30
seconds
PIR sensitivity level setting Green: Flashes 1-3 times according to
the selected level
Alarm detection Red: ON for 2 seconds
Booting/Tamper close Green/Red alternating flashes for 30
seconds
Anti-mask detection Orange: Flashes ON/OFF 3 times every
60 seconds
Specification Description
Infrared sensor type 2 Dual elements
Detection range • PET Immunity mode: 7.5m x 2m (25 x 7
ft)
• Sharp mode: 10 x 2m (33 x 7 ft)
Super Pet Immunity Pet size approximately 50cm
Anti- mask Active IR detection for blocking items 30cm
and sprayed liquid
Input voltage 10 to 15VDC
Current consumption Typical: 15mA
Maximum: 19.2mA
Compatibility EVO, Spectra and Magellan systems
Outdoor protection IP54
Operation temperature -35°c: +50°c
Relative humidity 95% non-condensing
Dimensions 12.3 x 6.1 x 4.3 cm (4.8 x 2.4 x 1.7 in.)
Certifications CE, EN50131-2-2 Grade 3, Class IV
Weight 100g / 0.2 lb
