SR150-EI11 12/2012 SR150 V2.1 PARADOX.COM
Programming
Upgrading the Firmware
The SR150 firmware can be upgraded through WinLoad using the 307USB Direct Connect Interface. Refer to the firmware upgrade instructions found at:
paradox.com - Software - WinLoad -Firmware Upgrade Instructions.
NOTE: Ensure that the SR150 Wireless Siren is awake before beginning the firmware upgrade. To wake up the siren, press the “test’ button. The siren will
provide you with a 60 second delay in order to begin the update.
Tamper Supervision
If a tamper is detected, the SR150 will sound an alarm and the strobe light will flash for 4 minutes. The control panel will follow the global supervision
options set in the panel.
For complete warranty information, please visit www.paradox.com/terms. Your use of the Paradox product signifies your acceptance of all warranty terms and conditions. Magellan, Spectra SP, EVO, and WinLoad are
trademarks or registered trademarks of Paradox Ltd. or its affiliates in Canada, the United States and/or other countries. For the latest product approvals, such as UL and CE, please visit www.paradox.com. © 2012 Paradox
Ltd. All rights reserved. Specifications may change without prior notice. One or more of the following US patents may apply: 7046142, 6215399, 6111256, 6104319, 5920259, 5886632, 5721542, 5287111, and RE39406 and
other pending patents may apply. Canadian and international patents may also apply.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
LED Feedback Specifications
Power 4.5Vdc (3 size “D” alkaline batteries)
Optional: 8-16Vac / 9-20Vdc external power
Battery life Up to 3 years based on normal use (e.g. 2 alarms per year
with strobe for 2.5 hours and 8 squawks per day at an
average of 25
ºC (77ºF). Using optional power source will
extend battery life.
Consumption Sleep: 22uA, Standby: 130uA, Alarm: 550mA
RF frequency 433MHz or 868MHz
Siren 100dB (1 meter)
Dimensions 24cm X 6.cm X 18cm (9.5in X 2.3in X 7in)
Operating
Temperature
Battery only: -30ºC to 50ºC (-22ºF to 122ºF)
RF range 70m (229ft)
Standards
EN 50131 Security Grade 2 Environmental Class IV
MG/SP Feature Details
[683] Learn Siren #1 Press and hold “TEST” switch for 3 seconds after entering the section
to learn the siren.
WARNING: When you press the “TEST” switch, the SR150 will squawk and
the strobe light will flash five times to confirm registration to the panel.
[684] Learn Siren #2
[685] Learn Siren #3
[686] Learn Siren #4
[687] Display Signal Strength Siren #1 Press and hold “Test” switch for 3 seconds after entering the section
to display, on a K32LCD V1.3 or higher, the signal strength the panel is
receiving from the siren.
[688] Display Signal Strength Siren #2
[689] Display Signal Strength Siren #3
[690] Display Signal Strength Siren #4
[691] Label Siren #1 These labels are used when reporting events via e-mail through the
IP100 and for troubleshooting purposes. Maximum 16 characters.
[692] Label Siren #2
[693] Label Siren #3
[694] Label Siren #4
[695] Temporary Tamper Switch Deactivation for
Maintenance
Press the [
ENTER] key after entering the section to deactivate tamper
alarm until the cover is replaced or after 30 minutes.
[587] Panel Supervision of Siren OFF = disabled ON = enabled (default)
Option [3] Siren #1 (OFF/ON) The control panel supervises the presence of the SR150. If lost, the
control panel will follow global supervision loss option set in the
panel.
Option [4] Siren #2 (OFF/ON)
Option [5] Siren #3 (OFF/ON)
Option [6] Siren #4 (OFF/ON)
TX Sending data
RX Receiving data
PSSI Signal strength siren is receiving from panel
Flash 4x - strong signal
Flash 3x - good signal
Flash 2x - weak signal
Flash 1x - very weak signal (relocate)
No flash - no signal
Status Flash once/sec. - Processor is on
Flash once/4 sec. - Power save mode
Remove cover to view
LED status
