Configuration Options
Configuration options are accessed from the Configuration branch of the front panel
menu.
In the following tables, FacT (Factory Tributary) defaults are shown in boldface. If
different from the FacT defaults, FacC (Factory Control) defaults are shown in italics.
Key to symbols:
D
When the Async→Sync configuration option is enabled using the General
branch, the following PrtSp(Kbps) settings do not appear:
32, 24.0, 18.8, 18.0, 9.2, 8.4, 4.4, 4.0, and 2.0 kbps
DD
19.2 Power Level defaults to +6 dB when App Module ID displays XLOOP
LL
V.32 Analog DBM only
A
These configuration options do not appear when Full mode is disabled using
Menu from the Configuration branch.
DSU
Configuration Options
Value
Rate(Kbps) Auto, 64CC, 64L, 56, 38.4, 19.2, 9.6, 4.8, 2.4
PrtSp(Kbps) D
64, 56, 48, 38.4, 32, 28.8, 24.0, 19.2, 18.8, 18.0, 16.8, 14.4, 12.0,
9.6, 9.2, 8.4, 7.2, 4.8, 4.4, 4.0, 2.4 , 2.0, 1.2, Disab
TxClkSource Int, RXC, Ext, DDS, Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
Msg Clamp A Enab, Disab
TxElasStor Enab, Disab
RxElasStor A Enab, Disab
19.2 PowrLvl DD A
+6, 0, –10
64KScramblng A On, Off
64KLatchLpbk A On, Off
NetIntf A AggSw, Forc, Disab
Net ITiming A Int, NetI, Prt1, Prt2, Prt3, Prt4, Prt5, Prt6
V.54 Lpbk A Enab, Disab
Diagnostic DSU
Configuration Options
Value
Diag Type NonD, Disr, Mixed, None
2nd Ch(bps) A 100, 400, 800, 1200, 1600
Disr Type 2500, 2600, 3600s, 3600e, Br56
