www.charltonandjenrick.co.uk 15 LT5052 (ISS 5)
SECTION FIVE Replacement Parts (user instructions)
The only user removable parts are: -
The loose pebbles or coals.
The left hand front pebble or coal shape
The right hand front pebble or coal shape.
The base matrix
Cast Fret
Decorative Trim
SECTION SIX Appliance Specification (installation instructions)
Data Label Location, Natural Gas & LPG: Top behind decorative trim.
Gas Connection, Natural Gas & LPG: 8 mm OD Tube.
Length of Flue 1 metre (max).
Length of Flue Pipe (Supplied) 435mm, 1 metre length available as an optional extra.
NATURAL GAS VERSION PROPANE GAS VERSION
Category of Appliance: B
AS
B
AS
Category I
2H
I
3P
Gas type: G20 G31
Gas Pressure: 20 mbar 37 mbar
Gas input high: 7.00kW Gross 7.00 kW Gross
Gas input low: 2.40kW Gross 2.40 kW Gross
Injector Main: Size 460 Size 135
Oxy-pilot NG9040 LPG9222
NOTE: The efficiency of this appliance has been measured as specified in BS7977-1 2009 + A1:2013 and the result is 50.9%. The gross calorific
value of the fuel has been used for this efficiency calculation. GasTec have certified the test data from which it has been calculated. The
efficiency value may be used in the UK Government’s Standard Assessment Procedure (SAP) for energy rating of dwellings.
