APPLICATIONS — LATCHING RELAYS
Objective: To turn lights ON and OFF in conjunction with a latching
relay. User must select the Momentary Option and clip the appropri-
ate jumper wire. See pages 22 - 23.
Sequence of Operation:
Relay contacts 6 and 7 close for two seconds to turn lights ON.
Relay contacts 3 and 4 close for two seconds to turn lights OFF.
Note that wiring diagrams differ for different models. Check product
label to make sure you are using the correct wiring diagram.
Figure 18. EC72 Latching Relay Wiring Diagram
40
