User Manual - Typhoon Open – 01/2018 edition
.
PARAMINA SA – Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: 0030 210 5575860-1
Fax: 0030 210 5575868, email: service@paramina.gr - website: www.paramina-compressors.com
36
6. Remove the coalescing cartridge & cover by pulling upwards.
7. Lay a small amount of silicone grease on the o-rings of filter’s base. If there is a trace of damage on the o-
rings, replace.
8. Install the new coalescing cartridge & cover on filter’s base by fastening it down with your hand.
9. Wrap a small amount of Teflon around the thread of the tube connector.
10. Clean the inside of the filter housing with a clean cloth.
11. Screw the filter housing back on its base.
12. Remove the new A.C.-M.S. cartridge from their protective case. Be sure that packaging is not punctured.
If it is damaged do not use it.
13. Lay a small amount of silicone grease on the o-ring of the new A.C.-M.S. cartridge.
14. Replace the two o-rings of the cartridge connector, lay a small amount of silicone grease on the new o-
rings and then screw the connector on the new A.C.-M.S. cartridge.
15. Place the new A.C.-M.S. cartridge in the filter housing and fasten it down by hand on the tube connector
(see also drawing nr. B).
16. Lay a small amount of silicone grease on the o-rings of the filter head. If there is a trace of damage on the
o-rings, replace.
17. Screw the filter head carefully by hand with light pressure until it fits evenly to the filter housing.
Do not screw really tight, while screwing cartridges or connectors inside filter’s housing.
FILTER HEAD & FILTER HOUSING SHOULD BE ADJOINED ON TOP WHEN REINSTALLING.
Parts & Codes
Filter head for Bleed Valve
AC/MS cartridge (active carbon/molecular sieve)
AC/MS/HP cartridge (active carbon/molecular sieve/hopcalite)
O-ring c.c. (connector cartridge)
Coalescing pre-filter Cover
O-ring filter head & base
Manual drain complete with seat
