Paramina Typhoon Open 15E User Manual

User Manual - Typhoon Open – 01/2018 edition
.
PARAMINA SA – Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: 0030 210 5575860-1
Fax: 0030 210 5575868, email: service@paramina.gr - website: www.paramina-compressors.com 48
Item
Qty
Part Nr.
Description
3.1
1
211670021
Oil filling plug
3.2
1
109460302
Air Intake filter cartridge
1
109000000
Air intake filter complete
3.3
1
219000022
Safety valve 2nd - 100bar series @45bar
3.4
1
208501620
Condensate separator 2
nd
Stage (go to page 63 for drawing)
3.5*
1
208905700
BA filter housing Ø80x535
208905710
BA filter housing Ø78x560 w/o Bleed Valve
208905720
BA filter housing Ø78x560 c/w Bleed Valve
208611492
BA filter housing Ø110x495
3.6
2
190000080
Manual drain valve complete with seat
2
190008112
Manual drain valve’s seat
3.7
1**
190000252
3
rd
stage aftercooler
3.8
1
190500610
1
st
stage safety valve (7bar)
3.9a
1
154122251
Auto drain 3
rd
stage 250 bar 12V
1
154122311
Auto drain 3
rd
stage 350 bar 12V
3.9b
1
219004552
3
rd
Stage Safety valve 250 bar ***
1
219004522
3
rd
Stage Safety valve 350 bar ***
3.10
1
154122241
Auto drain 2
nd
stage 80 bar 12V
3.11
1
104270092
Petrol engine 6,0 kW
1
104390132
Petrol engine 8,2 kW
1
133000472
Support Spring + bolt set
3.12
4
128604022
Anti-vibration pads
3.13
1
219004572
Pressure Maintaining valve ****
3.14
1
190000250
2
nd
stage intercooler
3.15
1
122063162
1
st
Stage Manometer
1
140004602
1
st
Stage Manometer Flexible Hose
3.16
1
122063102
2
nd
Stage Manometer
1
140000571
2
nd
Stage Manometer Flexible Hose
3.17
1
122063422
3
rd
Stage Manometer
1
140000622
3
rd
Stage Manometer Flexible Hose
3.18
1
401001082
Condensate collecting tank 6ltr
3.19
1
142111201
Silencer/Sintered Filter
3.20
1
190000240
1
st
stage intercooler
3.21
1
164305121
3
rd
stage pressure switch 40 – 400bar
3.22
1
104900001
Battery
3.23
4
105000510
Handle
3.24
1
103965181
Drains On led
3.25
1
160110302
Drains switch
1
160040202
3.26
1
*
V-Belt * According to compressor’s serial number.
10
182451921
Cooling fan blades
1
136368001
Flywheel
1
105009002
Fan guard set
