Paramina Typhoon Open 15E User Manual

User Manual - Typhoon Open – 01/2018 edition
.
PARAMINA SA – Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: 0030 210 5575860-1
Fax: 0030 210 5575868, email: service@paramina.gr - website: www.paramina-compressors.com 53
1
127126942
BA filter base o-ring
7
1
219004552
3
rd
Stage Safety valve 250 bar
219004522
3
rd
Stage Safety valve 350 bar
8
2
190000080
Manual drain valve complete with seat
2
190008112
Manual drain valve’s seat
9
1
190000252
3
rd
stage aftercooler
10
1
190500610
1
st
stage safety valve
11
1
140000080
Filling hose 1,2m 10L
140000921
Kevlar Filling hose 1,2m 8S
12
1
122063402
3
rd
Stage Manometer 400b
1
122063012
Manometer rubber cover
13
1
103030072
Electric Motor 5,5kW
103030052
Electric Motor 4kW
1
133000522
Support Spring + bolt set (Typhoon Electric)
14
4
128604022
Anti-vibration pads
15
1
219004572
Maintenance valve
16
1
190000250
2
nd
stage intercooler
17
1
190000240
1
st
stage intercooler
18
1
SERVICE KIT PART NUMBER: 189900200, O-RING PART NUMBER: 127052702
19
1
211640041
Oil sight glass
20
1
181357162
4kW Electric box c/w Start/Stop button & motor thermal
overload protection
1
181357212
5,5 kW Electric box c/w Start/Stop button & motor thermal
overload protection
* See all BA filter’s parts and codes in pages 26,30, 34 & 36.
