Sicherheitshinweise • safety instrucons • Informaons sur la sécurité • Información de seguridad • Indicazi-
oni generali di sicurezza • Veiligheidsinstruces • Ogólne zasady bezpieczeństwa • Genel Güvenlik Uyarıları
The extracon forces express the force necessary to extract a screw
from the wall. Here it will not be disnguished if the screw comes out
of the wall with the plug, if the screw or the masonry breaks.
The extracon forces declare how strongly screws and / or plugs can
be vercally strained. The xing material must be determined on the
basis of the mounng surface, the kind of assembly and the extrac-
on forces.
The awning has a wind resistance class 2 and must
be retracted in case the wind force is higher than 5.
The following chart explains the classes and shows the
wind speed and its eects.
Instrucons for the assembler and the user:
All the operang instrucons, assembly instrucons as well as adjust-
ment instrucons of the manufacturer of the motor, of the switcher
and of the control must be given to the user with a guide.
He must be comprehensively informed about the safety informaon
and user instrucons of the awning. Failure to observe this informa-
on and incorrect operaon may cause damage to the awning and
accidents. The instrucons must be kept and must be handed to the
new owner in case of the awning is given to a third. According to the
knowledge of the local condions and of the executed assembly, the
installaon company declares to the user if the wind resistance class
indicated by the manufacturer has been achieved in mounted con-
dion. If not, the installaon company must document the actually
achieved wind resistance class.
The user and the assembler shall be responsible for proper funco-
ning of the wind monitoring system and its regular check and funcon
monitoring. In case of storm damage occurred in spite of wind mo-
nitoring, the supplier and manufacturer of the awning do not accept
any warranty. Sensors with sun monitoring must be turned o over
the winter.
In case of improper use the risk of injury is higher:
- Instruct all the people in using the motor and the controls safely.
Please monitor the moving awning and keep away people unl the
movement is over
- Do not allow children to play with xed or remote controls.
- Please keep the hand transmier so that any undesired operaon,
e.g. by means of playing children is excluded.
- Carry out maintenance and cleaning work on the awning exclusively
in absence of voltage.
In case of permanently installed devices, in compliance with DIN VDE
0700, an energy-isolaon device for each phase must be present on
the part of the installaon.
As energy-isolang devices, switches with a contact opening width of
min. 3 mm (e.g. Miniature Circuit Breaker or Residual Current Ope-
rated Circuit-Breaker) count. Please check the installaon regularly.
In case of damage (e.g. signs of deterioraon, damaged cables, and
misplaced end posions) the system is not allowed to be used
Note for the electrician:
This awning is not allowed to be connected under voltage. Turn o
the circuit breaker in advance! The system must be secured by means
of a residual current operated circuit-breaker in compliance with VDE.
For the electrical connecon, it is allowed to use exclusively cables
and plug connecons with a protecon class of at least IP 54
Connecon & start-up:
Connect the motor according to the connecon instrucons. To pre-
vent that water penetrates the motor, the connecon cable should be
always laid downwards with a loop.
Care and maintenance:
The awning is basically maintenance-free. All aluminium parts have
a high-quality powder coang, as well as the screw connecons of
stainless steel.
No corrosion may occur to these components. We advise to clean the
cassee every 6 weeks with a damp cloth.
The awning cloth has a high-quality coang and is therefore suitable
for outside use.
If the awning cloth becomes wet by rain, nothing will happen. The
awning cloth may be rolled up wet, too. However, in this case, we
advise to roll it out again and let it dry when it does not rain anymore.
We advise for the cleaning a soluon of laundry detergent and a so
brush. You can achieve good results in case of stubborn stains also
with a rubber. Never clean by means of a high-pressure device, becau-
se it damages the waterproong.
Product features of awning coverings
We process exclusively high-quality polyester fabrics in our awnings.
The bre of the weaving yarn is spun-dyed and therefore also UV-re-
sistant (colour- and light-fast).
A renement of the surface gives the cloth water-repellent and
dirt-repellent properes. Mould formaon is this way also prevented.
Important consumer informaon:
Awning covers are high-performance products. However, limits to
their perfecon are set by environmental protecon requirements
and with the current state of technology. Certain phenomena in the
fabric, which somemes are subject of complain, are possible in spite
Klasse Wind force Wind speed Eects
0 1 -3 up to 19 km/h
Leaves and thin twigs
move
1 4 20 - 28 km/h
Twigs and thin branches
move, loose paper is lied
from the oor
2 5 29-38 km/h
Branches move and small
deciduous trees uctuate
3 6 39 - 49 km/h
Thick branches uctua-
te, umbrellas used with
diculty
Technical data
Motor type: TDMK-B
Voltage: 230 V
Frequency: 50 Hz
Rotaonal speed: 13 U/min
Current consumpon: 1,06 A
Power: 244 W
Operang me: 4 min
Torque: 50 Nm
Emission sound pressure: < 70 dB
