Park Central Arch - Single Post Footing Layouts

SWING FRAMES
DATE: 08/29/2014
INSTALLATION GUIDELINES
Page 17 of 20
SINGLE 5” POST FRAME - ONE BAY
SINGLE 5” POST FRAME - TWO BAY
SINGLE 5” POST FRAME - THREE BAY
SINGLE 5” POST FRAME - FOUR BAY
138”
18”X36”
DEEP
138”
18”X36”
DEEP
138”
138”
18”X36”
DEEP
138”138”
138”
18”X36”
DEEP
138”138” 138”
