Park Tool PRS-20 - Parts List; Detailed Part Numbers and Descriptions

Park Tool Co.
5115 Hadley Ave. N., St. Paul, MN 55128 (USA) www.parktool.com
© 2013 Park Tool Co. / PARK TOOL® and the color BLUE are registered trademarks of Park Tool Co.
Note: Washers should be used as required to account for variations in casting taper.
Part No. Description
Qty.
1729A Front Quick Release Assembly 1
1722A Rear Quick Release Assembly 1
1728 Slider Tube Weldment 1
1721 Slider Rear Axle Extension 1
1706-2 Knob and Shaft 2
1715-2 Horizontal Beam End Cap 2
1716R Horizontal Beam Tube (PRS-20 only) 1
1734R Aluminum Horizontal Beam Tube (PRS-21 only) 1
1257-2 Saddle Button Head Socket Cap Screw 1/4 - 20 x 3/8” 2
1711R Bottom Bracket Saddle 1
1283X Pivot Button Head Socket Cap Screw M10 x 50 1
1723 Hitch Pin 1
1724-2 Bracket Washer 2
1285X Pivot Screw Nylok Nut 1
1709L Left Upright Bracket 1
1709R Right Upright Bracket 1
1709S Buckle & Strap Assembly 1
290 Nylok Nut 2
1709-2 Upright Bracket Bolt 2
1708 Upright Tube (PRS-20 only) 1
1733 Aluminum Upright Tube (PRS-21 only) 1
1707.2 Clamping Collar Quick Release Assembly 1
1701 Upright Sleeve 1
1705 Yoke Weldment (PRS-21 only) 1
1705-20 Yoke Weldment (PRS-20 only) 1
479-6 Leg Bolt 1/4 - 20 x 2” 3
1700-3 Leg Tube (PRS-20 only) 3
1732-3 Aluminum Leg Tube (PRS-21 only) 3
1780-2 Leg Cap 3
480-6 Leg Nylok Nut 1/4 - 20” 3
1
2
3
4
5
6
7
7
8
9
10
11
12
13
14
15
16
17
18
19
19
20
21
22
22
23
24
24
25
26
PRS-20, PRS-21
Team Race Stand
