Tab. 2 - Spare Parts List HFN005-72 (see Fig.5)

Parts Description

Models, Codes

005 010 018 022 030 045 062 072

1.(*)

filter element

Grade Q (D)

model Q005 Q010 Q018 Q022 Q030 Q045 Q072

code Q005-

ELZ

Q010-

ELZ

Q022-ELZ Q030-

ELZ

Q045-

ELZ

Q072-ELZ

filter element

Grade P

model P005 P010 P018 P022 P030 P045 P072

code P005-

ELZ

P010-

ELZ

P022-ELZ P030-

ELZ

P045-

ELZ

P072-ELZ

filter element

Grade S

model S005 S010 S018 S022 S030 S045 S072

code S005-

ELZ

S010-

ELZ

S022-ELZ S030-

ELZ

S045-

ELZ

S072-ELZ

filter element

Grade C

model C005 C010 C018 C022 C030 C045 C072

code C005-

ELZ

C010-

ELZ

C022-ELZ C030-

ELZ

C045-

ELZ

C072-ELZ

HDI2

internal drain

HDI2

manual

condensate drain

398H698399 (see fig.5)

CDV 120 external drain

(230V 17.24 bar)

CDV120230

CDV 120 external drain

(115V 17.24 bar)

CDV120115

CDV 120 external drain

(24V 17.24 bar)

CDV12024

differential pressure

gauge(optional)

ESG2

differential pressure

indicator (optional)

ESIXHFN005-370

in-series connection

nipples (optional)

398H324576 398H324582 398H324577 398H324578 398H324579 398H324580 398H324581

wall mounting kit

(optional)

WMKXHF

N005

WMKXHFN010-022 WMKXHFN030-072

(*) Consumable material
