TWP/TWB200 – TWP/TWB9000
47
MODBUS REGISTER MAP (CONT’D)
Address R/W Description Notes
10046 R Output - Right Pre-Exhaust Valve Right pre-exhaust valve is open
(Only dryers with pre-exhaust valves)
10047 R Output - Left Exhaust Valve Left Exhaust valve is open
10048 R Output - Right Exhaust Valve Right Exhaust valve is open
10049 R Output - Open Left Inlet Valve Left Inlet Valve is open (Dual acting Inlet valves only)
10050 R Output - Open Right Inlet Valve Right Inlet Valve is open (Dual acting Inlet valves only)
10051 R Output - Close Left Inlet Valve Left Inlet Valve is Closed
10052 R Output - Close Right Inlet Valve Right Inlet Valve is Closed
10066 R Input - Sensor Power Sense 1 = sensor power present
0 = blown fuse or missing power
10067 R Input - Emergency Stop Switch 1 = Normal switch position (No Emergency Stop )
0 = Emergency Stop Pressed
10068 R Input - Blower Overload 1 = Blower Overload (Blower Models only)
10069 R Input - Blower Flow Switch 1 = Blower Flow Switch Closed (Active) (Blower Models only)
10071 R Input - Drain Switch #1 1 = drain switch closed (Demand drains only)
10072 R Input - Drain Switch #2 1 = drain switch closed (Demand drains only)
10073 R Input - Over-temp Sense 1 = Over-temp module normal operation
0 = Over-temp module has tripped on high temperature.
Heaters are disabled
10074 R Input - Output Power Sense 1 = Output power is present,
0 = Blown fuse or missing power
10078 R Input - Run/Stop Switch 1 = External Run/Standby Switch set to Standby Position
10079 R Input - Remote Alarm Reset 1 = External contact closure resets Alarms and Restart Dryer
10081 R Alarm - Left Blowdown see separate alarm chart for details
10082 R Alarm - Right Blowdown see separate alarm chart for details
10083 R Alarm - Left Repressurization see separate alarm chart for details
10084 R Alarm - Right Repressurization see separate alarm chart for details
10085 R Alarm - High Purge Temperature see separate alarm chart for details
10086 R Alarm - Low Purge Temperature see separate alarm chart for details
10087 R Alarm - High Over Temperature see separate alarm chart for details
10089 R Alarm - Left Mufer see separate alarm chart for details
10090 R Alarm - Right Mufer see separate alarm chart for details
10091 R Alarm - Low Purge Pressure see separate alarm chart for details
10092 R Alarm - Inlet Temperature see separate alarm chart for details
10093 R Alarm - Inlet Pressure see separate alarm chart for details
10094 R Alarm - High Dewpoint see separate alarm chart for details
10095 R Alarm - Pre-lter see separate alarm chart for details
10096 R Alarm - After-lter see separate alarm chart for details
10097 R Alarm - Blower Motor Overload see separate alarm chart for details
10100 R Alarm - Blower Flow Switch see separate alarm chart for details
10101 R Alarm - Drain #1 Switch see separate alarm chart for details
10102 R Alarm - Drain #2 Switch see separate alarm chart for details
10103 R Alarm - Aux Sensor Input #1 Low see separate alarm chart for details
10104 R Alarm - Aux Sensor Input #1 High see separate alarm chart for details
