TWP/TWB200 – TWP/TWB9000
46
MODBUS REGISTER MAP
Address R/W Description Notes
10001 R Status - Heated Mode Running in Heated mode
10002 R Status - Heatless Mode Running in Heatless mode
10003 R Status - Switching to Heated Switching from Heatless to Heated
10004 R Status - Switching to Heatless Switching from Heated to Heatless
10005 R Status - Extended Drying Active Variable drying time conditions met
10006 R Status - Extended Dry Purge Active Currently using extended dry purge
10007 R Status - Stepping Allowed Stepping is currently Allowed
10008 R Status - Manual Stepping Active Manual stepping is currently enabled
10009 R Status - Run/Stop Status Drying is currently running
10010 R Status - Dryer is Parked Dryer is in Standby
10011 R Status - Heating Exhaust Limits Met Heating exhaust conditions have been met
10012 R Status - Cooling Exhaust Limits Met Cooling exhaust conditions have been met
10013 R Status - Shutdown Currently shutdown due to alarm
10014 R Status - Active alarm There are current active alarms
10015 R Status - Control Air Control Air pressure is above its setting
10016 R Status - Restarting Dryer Dryer is currently restarting after an alarm
10017 R Status - Repressurizing Currently the dryer is repressurizing both tanks
10018 R Status - Regenerating Currently the dryer is regenerating in Heatless operation
10019 R Status - Heating Currently regenerating using heated air
10020 R Status - Blower Cooling Currently operating in the heating stage of regeneration
10021 R Status - Ambient (Blower) Cooling Currently using blower to provide ambient air for cooling
10022 R Status - Stripping Currently using dry purge air for cooling
10023 R Status - Drying Side 0 = Left Tower Drying
1 = Right Tower Drying
10024 R Status - Regeneration Side 1 = Left Tower Regenerating
0 = Right Tower Regenerating
10025 R Status - Blowing Down Regenerating tower is currently blowing down
10026 R Status - Remote Shutdown Remotely shutdown the dryer
10027 R Status - Remote Standby Remotely place the dryer in Standby
10028 R Status - OK to Switch Tank pressures are ok to switch towers or open exhaust valves
10033 R Output - Alarm Relay Relay is active
10034 R Output - Repressurization Valve Repressurization valve is open
10035 R Output - Purge Stop Valve Purge stop valve is closed
(Blower Models Only)
10036 R Output - Dry Purge Valve Dry Purge valve is open (Externally Heated Models Only)
10037 R Output - Drain #1 Valve Drain valve is open
10038 R Output - Drain #2 Valve Drain valve is open
10039 R Output - Blower Contactor Blower is running (Blower Models Only)
10040 R Output - Purge Heater Contactor Heater is active
10041 R Output - Over Temp Contactor Over-temp contactor is closed allowing heating
10042 R Output - Purge Heater Contactor Bank 2 Heater Bank #2 is active (Only dryers with Multi-Bank Heaters)
10043 R Output - Purge Heater Contactor Bank 3 Heater Bank #3 is active (Only dryers with Multi-Bank Heaters)
10044 R Output - Purge Heater Contactor Bank 4 Heater Bank #4 is active (Only dryers with Multi-Bank Heaters)
10045 R Output - Left Pre-Exhaust Valve Left pre-exhaust valve is open
(Only dryers with pre-exhaust valves)
