Parker Airtek TWB800 User Manual

TWP/TWB200 – TWP/TWB9000
49
MODBUS REGISTER MAP (CONT’D)
30125 R Control Outputs Register #1 Mirrors bit registers 10033 thru 10048
30126 R Control Outputs Register #2 Mirrors bit registers 10049 thru 10064
30127 R Switch Input Data Register #1 Mirrors bit registers 10065 thru 10080
30128 R Switch Input Data Register #2 Mirrors bit registers 10081 thru 10096
40001 R/W Alarm Set - Over Temperature see separate alarm chart for details
40002 R/W Alarm Set - High Inlet Temperature see separate alarm chart for details
40003 R/W Alarm Set - Low Inlet Pressure see separate alarm chart for details
40004 R/W Alarm Set - High Dewpoint see separate alarm chart for details
40005 R/W Alarm Set - High After-Filter Pressure see separate alarm chart for details
40006 R/W Alarm Set - High Pre-Filter Pressure see separate alarm chart for details
40008 R/W Alarm Set - Low Purge Temperature see separate alarm chart for details
40009 R/W Alarm Set - User Sensor #1 Low Setpoint see separate alarm chart for details
40010 R/W Alarm Set - User Sensor #1 High Setpoint see separate alarm chart for details
40011 R/W Alarm Set - User Sensor #2 Low Setpoint see separate alarm chart for details
40012 R/W Alarm Set - User Sensor #2 High Setpoint see separate alarm chart for details
40013 R/W Calibration - Sensor Min Set - Left Tower Pressure Minimum sensor pressure. Default is 0 psi
40014 R/W Calibration - Sensor Min Set - Right Tower Pressure Minimum sensor pressure, Default is 0 psi
40015 R/W Calibration - Sensor Min Set - Inlet Pressure Minimum sensor pressure, Default is 0 psi
40016 R/W Calibration - Sensor Min Set - Output Pressure Minimum sensor pressure, Default is 0 psi
40017 R/W Calibration - Sensor Min Set - Purge Pressure Minimum sensor pressure, Default is 0 psi
40018 R/W Calibration - Sensor Low Set - Dewpoint Probe Minimum sensor dewpoint, Default is -148°F
40019 R/W Calibration - Sensor Min Set - User Sensor #1 User adjustable input #1 minimum range.
Default is 0. Refer to register 40039.
40020 R/W Calibration - Sensor Min Set - User Sensor #2 User adjustable input #2 minimum range.
Default is 0. Refer to register 40040.
40021 R/W Calibration - Sensor Max Set -
Left Tower Pressure
Maximum sensor pressure, Default is 200 psi
40022 R/W Calibration - Sensor Max Set -
Right Tower Pressure
Maximum sensor pressure, Default is 200 psi
40023 R/W Calibration - Sensor Max Set - Inlet Pressure Maximum sensor pressure, Default is 200 psi
40024 R/W Calibration - Sensor Max Set - Outlet Pressure Maximum sensor pressure, Default is 200 psi
40025 R/W Calibration - Sensor Max Set - Purge Pressure Maximum sensor pressure, Default is 200 psi
40026 R/W Calibration - Sensor Max Set - Dewpoint Probe Maximum dewpoint. Default is 68°F
40027 R/W Calibration - Sensor Max Set - User Sensor #1 User adjustable input #1 maximum range, Default is 100
40028 R/W Calibration - Sensor Max Set - User Sensor #2 User adjustable input #2 maximum range, Default is 100
40029 R/W Calibration - Sensor Offset Set - Left Tower Pres-
sure
Sensor offset, Default is 0 psi
40030 R/W Calibration - Sensor Offset Set - Right Tower
Pressure
Sensor offset, Default is 0 psi
40031 R/W Calibration - Sensor Offset Set - Inlet Pressure Sensor offset, Default is 0 psi
40032 R/W Calibration - Sensor Offset Set - Outlet Pressure Sensor offset, Default is 0 psi
40033 R/W Calibration - Sensor Offset Set - Purge Pressure Sensor offset, Default is 0 psi
40034 R/W Calibration - Sensor Offset Set - Dewpoint Probe Sensor offset, Default is 0°F
40035 R/W Calibration - Sensor Offset Set - User Sensor #1 User adjustable input #1 offset
40036 R/W Calibration - Sensor Offset Set - User Sensor #2 User adjustable input #2 offset
40037 R/W Calibration - System Display Temperature Units 0 = F, 1 = C., Does not affect Modbus register units.
