MODBUS REGISTER MAP (CONT’D)
40069 R/W Control Setting - Variable Cycling Time Enable 1 = Enable dewpoint demand function
40070 R/W Control Setting - Extended Dry Purge 1 = Enable 2% dry purge feature, Blower model only
40071 R/W Control Setting - Enable Manual Stepping 1= Enable manual stepping. 0 = Disable manual stepping.
Use with Caution!
40072 R/W Control Setting - Step to Next State Set to 1 to step to the next state, 40072 must be set rst,
Caution! Do NOT Step out of cooling without considering the
temperature in the regenerating tower. Instead, wait for cooling
cycle to complete
40073
R/W Control Setting - Remote Shutdown Set to remotely shutdown the dryer
40074 R/W Control Setting - Remote Standby Set to remotely place the dryer in standby.
40075 R/W Control Setting - Heating Exhaust Limits Enable Default is 1, Heating Exhaust Limits are active
40076 R/W Control Setting - Cooling Exhaust Limits Enable Default is 0, Cooling Exhaust Limits are not active
40077 R/W Control Setting - Enable Inlet Filter Display inlet lter pressure and enable alarm
40078 R/W Control Setting - Store Factory Settings Store copy of settings in PLC
40079 R/W Control Setting - Recall Factory Settings Restore copy of settings in PLC
40080 R/W Control Setting - Dewpoint Sensor Enable Dewpoint sensor is installed
40081 R/W Control Setting - Test Drains Set to re drains.
40084 R/W Control Setting - Enable Dual Acting Valve Factory Setting - Dryer uses dual acting inlet valves
40085 R/W Control Setting - Enable Pre-Exhaust Outputs Factory Setting - Dryer uses pre-exhaust valves
40086 R/W Alarm Setting - Acknowledge Alarms Set to silence the alarm display and turn off the alarm relay until
next alarm occurs
40087 R/W Alarm Setting - Clear all alarms Reset all alarms, Restarts dryer if it is shutdown.
40088 R/W Alarm Setting - Blowdown Alarm Enabled see separate alarm chart for details
40089 R/W Alarm Setting - Dewpoint Alarm Enabled see separate alarm chart for details
40090 R/W Alarm Setting - Low Inlet Pressure Alarm Enable see separate alarm chart for details
40091 R/W Alarm Setting - High Inlet Temp Alarm Enabled see separate alarm chart for details
40092 R/W Alarm Setting - After-Filter Alarm Enabled see separate alarm chart for details
40093 R/W Alarm Setting - Pre-Filter Alarm Enabled see separate alarm chart for details
40094 R/W Alarm Setting - Repressurization Alarm Enabled see separate alarm chart for details
40095 R/W Alarm Setting - Aux Sensor #1 Low Alarm Enabled see separate alarm chart for details
40096 R/W Alarm Setting - Aux Sensor #1 High Alarm Enabled see separate alarm chart for details
40097 R/W Alarm Setting - Aux Sensor #2 Low Alarm Enabled see separate alarm chart for details
40098 R/W Alarm Setting - Aux Sensor #2 High Alarm Enabled see separate alarm chart for details
40099 R/W User Sensor #1 Input Enable Enables user input # 1
40100 R/W User Sensor #2 Input Enable Enables user input # 1
40101 R/W Control - Reboot HMI Remotely Remotely reboot the HMI, Useful if VNC server shuts down
unexpectedly due to high network trafc
