Parker Airtek TWB800 User Manual

TWP/TWB200 – TWP/TWB9000
62
Externally Heated Spare Parts List (Flow schematic drawing# FS11685)
MODEL TWP4000 TWP5000 TWP6000 TWP7500 TWP9000
DESICCANT PART ID PART NUMBER
DESICCANT 25LB BAGS (QTY) AV1, AV2 PDA-1/8-25 (232) PDA-1/8-25 (288) PDA-1/8-25 (352) PDA-1/8-25 (456) PDA-1/8-25 (540)
FILTER ELEMENTS
COALESCER ELEMENT (QTY) PF1, PF2 6CU51-280 X 1 (3) 6CU51-280 X 1 (4) 6CU51-280 X 1 (4) 6CU51-280 X 1 (7) 6CU51-280 X 1 (7)
PARTICULATE ELEMENT (QTY) AF1, AF2 10DS85-360 X 1 (1) 10DS85-360 X 1 (1) 10DS51-280 X 1 (3) 10DS51-280 X 1 (4) 10DS51-280 X 1 (4)
CONTROL AIR FILTER ELEMENT (QTY) CF1 TP2201-PE (1) TP2201-PE (1) TP2201-PE (1) TP2201-PE (1) TP2201-PE (1)
REPAIR KITS
INLET VALVE REPAIR KIT PV2, PV3 TP7661-BD-HP-RK TP7661-BD-HP-RK TP7661-BD-HP-RK TP7681-BD-HP-RK TP7681-BD-HP-RK
INLET VALVE ACTUATOR PV2, PV3 TP7631-BD-HP-A TP7631-BD-HP-A TP7631-BD-HP-A TP7681-BD-HP-A TP7681-BD-HP-A
EXHAUST VALVE REPAIR KIT PV1, PV4 TP7631-BD-HP-RK TP7641-BD-HP-RK TP7641-BD-HP-RK TP7641-BD-HP-RK TP7641-BD-HP-RK
EXHAUST VALVE ACTUATOR PV1, PV4 TP7532-B-HP-A TP7542-B-HP-A TP7542-B-HP-A TP7542-B-HP-A TP7542-B-HP-A
PRE EXHAUST VALVE REPAIR KIT PV7, PV8 TP7515-P1-RK TP7520-P1-RK TP7520-P1-RK TP7520-P1-RK TP7520-P1-RK
OUTLET CHK VALVE REPAIR KIT CV1, CV2 TP7461-SWRK TP7461-SWRK TP7461-SWRK TP7481-SWRK TP7481-SWRK
PURGE CHK VALVE REPAIR KIT CV3, CV4 TP7431-SWRK TP7431-SWRK TP7431-SWRK TP7441-SWRK TP7441-SWRK
PURGE CHK VALVE REPAIR KIT CV5, CV6 TP7420-AB-RK TP7420-AB-RK TP7420-AB-RK TP7420-AB-RK TP7420-AB-RK
REPRESS VALVE REPAIR KIT PV5 TP7610-P1-RK TP7615-P1-RK TP7615-P1-RK TP7615-P1-RK TP7615-P1-RK
PURGE STOP VALVE REPAIR KIT S9 TP7615-P1-RK TP7620-P1-RK TP7620-P1-RK TP7620-P1-RK TP7620-P1-RK
REPLACEMENT PARTS
INLET VALVE PV2, PV3 TP7661-BD-HP TP7661-BD-HP TP7661-BD-HP TP7681-BD-HP TP7681-BD-HP
EXHAUST VALVE P1, PV4 TP7532-B-HP TP7542-B-HP TP7542-B-HP TP7542-B-HP TP7542-B-HP
PRE EXHAUST VALVE PV7, PV8 TP7515-P1 TP7520-P1 TP7520-P1 TP7520-P1 TP7520-P1
OUTLET CHECK VALVE CV1, CV2 TP7461-SW TP7461-SW TP7461-SW TP7481-SW TP7481-SW
PURGE CHECK VALVE CV3, CV4 TP7431-SW TP7431-SW TP7431-SW TP7441-SW TP7441-SW
PURGE CHECK VALVE CV5, CV6 TP7420-AB TP7420-AB TP7420-AB TP7420-AB TP7420-AB
REPRESS CONTROL SOELNOID VALVE S5 TP8101-D TP8101-D TP8101-D TP8101-D TP8101-D
REPRESS VALVE PV5 TP7610-P1 TP7615-P1 TP7615-P1 TP7615-P1 TP7615-P1
PURGE STOP VALVE PV9 TP7615-P1 TP7620-P1 TP7620-P1 TP7620-P1 TP7620-P1
CONTROL SOLENOID VALVE S2A, S2B, S3A, S3B TP8101-1D TP8101-1D TP8101-1D TP8101-1D TP8101-1D
CONTROL SOLENOID VALVE S1, S4, S7, S8, S9 TP8101-1D TP8101-1D TP8101-1D TP8101-1D TP8101-1D
DRAIN VALVE S10, S11 TP8003 TP8003 TP8003 TP8003 TP8003
MUFFLER, EXHAUST ES1, ES2 TP4215-1 TP4220-1 TP4220-1 TP4220-1 TP4220-1
FILTER, CONTROL AIR CF1 TP2201-P TP2201-P TP2201-P TP2201-P TP2201-P
SAFETY RELIEF VALVE PSV1, PSV2, PSV3, PSV4 TP7120 TP7120 TP7120 TP7120 TP7130-150
PRESSURE GAUGE PI1, PI2 LP1045 LP1045 LP1045 LP1045 LP1045
PRESSURE GAUGE PI3 LP1020 LP1020 LP1020 LP1020 LP1020
PURGE ORIFICE RO1 TP4475-1530 TP4499-2030-F TP4499-2030-F TP4499-2030-F TP4499-9
BACKUP PURGE ORIFICE RO2 TP4156 TP4463-1525 TP4468-1525 TP4478 TP4478
THERMOCOUPLE TC1,TC2,TC3,TC4,TC5,TC6 TP2082-UNGRD TP2082-UNGRD TP2082-UNGRD TP2082-UNGRD TP2082-UNGRD
VESSEL MANWAY GASKET AV1, AV2 FM21216-G FM21216-G FM21216-G FM21216-G FM21216-G
HEATER HT1 TP3650-4 TP3650-4 TP3660-4 TP3685-4 TP37100-8
PRESSURE TRANSDUCER PT1,PT2,PT3,PT4,PT5 TP2451 TP2451 TP2451 TP2451 TP2451
FUSE, HEATER EF3040-F EF3040-F EF3050-F EF3045-F EF3040-F
CONTACTOR C1,C2,C3,C4,C5,C6,C7,C8 ES5075 ES5075 ES5075 ES5075 ES5075
PLC PLC1 TP2681-PLC-P1500 TP2681-PLC-P1500 TP2681-PLC-P1500 TP2681-PLC-P1500 TP2681-PLC-P1500
HMI DISPLAY HMI TP2681-HMI-P1500 TP2681-HMI-P1500 TP2681-HMI-P1500 TP2681-HMI-P1500 TP2681-HMI-P1500
FUSE, 1 AMP F1, F3 EF0100-2-TD EF0100-2-TD EF0100-2-TD EF0100-2-TD EF0100-2-TD
FUSE, 3 AMP F2 EF0300-2-TD EF0300-2-TD EF0300-2-TD EF0300-2-TD EF0300-2-TD
MEMORY CARD TP2681-MEM TP2681-MEM TP2681-MEM TP2681-MEM TP2681-MEM
DEWPOINT PROBE AE1 TP2190-1 TP2190-1 TP2190-1 TP2190-1 TP2190-1
MODELS WITH NEMA 4
NEMA 4 THERMOCOUPLE TC1,TC2,TC3,TC4,TC5,TC6 TP2083-N4-12 TP2083-N4-12 TP2083-N4-12 TP2083-N4-12 TP2083-N4-12
MODELS WITH INSTRUMENTATION OPTION
PRESSURE GAUGE PI4, P5 LP1020 LP1020 LP1020 LP1020 LP1020
TEMPERATURE GAUGE TG1, TG2 LT3250-.25 LT3250-.25 LT3250-.25 LT3250-.25 LT3250-.25
