13
GB
Working without the automatic leveller
NOTES:
The leveller light [] will illuminate permanently in red when working
without the automatic leveller. The laser lines depicted are not
levelled.
The product has 2 magnets [2]. The magnets allow you to attach the
product to surfaces that attract magnetic objects, e.g. steel shelves.
m
ATTENTION! The magnetic surface used should be flat and not
curved or uneven surface. Otherwise, the product will fall down and
will be damaged.
1. Push the levelling slide switch [] to the right (closed lock).
2. Switch on the product.
Working with the tripod
(Fig. B)
Screwing the laser onto the tripod mount []
Screw the internal thread [] of the product hand tight onto the tripod
screw [].
Removing/inserting the tripod mount
1. Open the lever [6].
2. Remove the tripod mount [] in an upward direction.
3. Place the tripod mount [] on the tripod for insertion.
4. Lock the tripod mount [] by closing the lever [6].
m
ATTENTION! Do not use excessive force. This may damage the
product.
