8 GB
Description of parts
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the product.
(Fig. A)
[1] 360° laser
[2] Magnets
[3] Charging socket
[4] Butterfly screw
[5] Handwheel bolt
[6] Lever
[7] Tripod legs
[8] Snap fasteners
[9] Locking ring
[] Crank handle
[] Locking ring
[] Adjusting screw
[] Dragonfly (bubble vial)
[] Levelling slide switch
[] Charge indicator
[] On/off button
[] Leveller light
[] Vertical laser
[] Tripod mount
[] USB-C charging cable
(Fig. B)
[] Internal thread [] Tripod screw
Technical data
Working range: 20 m*
Weight (without tripod): approx. 440 g
Operating voltage U
max
: 4 V
Nominal capacity: 2.6 Ah
Charging voltage U
IN
: 5 V
Charging current: 1.7 A
Self-levelling range: ± 3°
Levelling accuracy: ± 0.4 mm/m
Laser wavelength: 510–530 nm
Laser class: 2
Levelling time: approx. 4 seconds
* The working range may be restricted by environmental conditions
(e.g. bright light).
