GB
9
z Technical Specifications
Output: 15–40 A
Input: 230 V~ 50 Hz
Weight (with accessories): approx. 11 kg
Dimensions: 396× 200x 245 cm
Insulation class: H
Cutting performance: 0.1 mm – 12 mm (depending on the material)
Copper: 1–4 mm
Stainless steel: 1–8 mm
Aluminium: 1–8 mm
Iron: 1–10 mm
Steel: 1–12 mm
Working pressure: 4–4.5 bar
Pressure of the integrated compressor: 2.5–4 bar
Airborne noise from the compressor in accord-
ance with ISO 3744:2010:
Under load:
Lpm (medium sound pressure level) 81.00 dB(A)
Lw (sound power level) 88.98 dB (A)
Without load:
Lpm (medium sound pressure level) 81.67 dB(A)
Lw (sound power level) 89.65 dB (A)
Measuring uncertainty: 1 dB(A)
Changes to technical and visual aspects of the product may be made as part of future developments
without notice. Accordingly, no warranty is offered for the physical dimensions, information and
specifications in these operating instructions. The operating instructions cannot therefore be used as the
basis for asserting a legal claim.
z Safety instructions
Please read through the operating instructions
carefully before use. Familiarise yourself with the device, its proper
use and the safety instructions based on these operating instructions.
These form part of the product and must be available at all times.
RISK OF SERIOUS INJURY OR DEATH FOR
INFANTS AND CHILDREN!
Never leave children unsupervised near packaging material. There is
a risk of suffocation.
This device may be used by children aged 16 years and older,
and by persons with reduced physical, sensory or mental capaci-
ties, or a lack of experience and knowledge, if they are supervised
