Intended purpose
into brick, concrete and stone, for chisel-
ling into concrete, stone and plaster, and
for drilling into stone, wood and metal.
Any other use that is not explicitly ap-
proved in these instructions may result in
damage to the equipment and represent a
serious danger to the user.
-
cidents causing injury to other people or
suitable for commercial use. Commercial
use will invalidate the guarantee.
-
charged using chargers from the Parkside
General description
An illustration of the most
important functional compo-
nents can be found on the fold-out page.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete:
- Cordless hammer drill
- Depth stop
- Auxiliary handle
- Case
- Instruction Manual
Battery and charger are not included.
Observe the safety informa-
tion and notes on charging
and proper use as shown
in the instruction manual
for your battery and char-
ger from the Parkside
A detailed description of the
charging process and further
information can be found in
the separate operating inst-
ructions.
Overview
1 SDS Plus tool holder
2 Dust protection cap
3 Locking sleeve
3a Mounting area for auxiliary handle
4 Function selection retaining knob
5 Function selection switch
6 On/off switch
7 Direction of rotation switch
8 Button for unlocking the battery
9 Battery (not included)
10 Smart LED display
11 Speed preselection
12 Battery charge level indicator
13 Case
14 Depth stop
15 Auxiliary handle
16 Loop
17 LED working light
18 Locking screw of depth stop
19 Handle
Description of functions
with an SDS-Plus tool holder, right/left rota-
tion, and an integrated LED work light.
