6 GB/IE
Cordless drill PABS 20-Li A1
Introduction
We congratulate you on the purchase of your new
device. You have chosen a high quality product. The
instructions for use are part of the product. They
contain important information concerning safety,
use and disposal. Before using the product, please
familiarise yourself with all of the safety information
and instructions for use. Only use the unit as de
scribed
and for the specified applications. If you pass the
product on to anyone else, please ensure that you
also pass on all the documentation with it.
Intended purpose
This appliance is designed for drilling and screwing
into wood, plastic and metal. Use the appliance only
as described and only for the purposes indicated.
Any other uses, and modifications to the appliance,
are deemed to be improper usage and may result
in serious physical injury. The manufacturer accepts
no responsibility for damage(s) resulting from
improper usage. The appliance is not intended for
commercial use.
Equipment Components
1
Gear selector switch
2
Torque pre-selector
3
Drill chuck
4
LED working light
5
Direction of rotation switch / lock
6
ON / OFF Switch / R.P.M. regulator
7
Battery pack release button
8
Rechargeable battery pack
9
Bit holder
10
Belt clip
11
Rechargeable battery charge state button
12
Rechargeable battery display LED
13
Fast charger
14
Red charge-control LED
15
Green charge-control LED
Scope of delivery
1 Cordless drill with rechargeable battery pack
1 Bit PH2 50 mm
1 Fast charger
1 Carry case
1 Directions for use
Technical Data
PABS 20-Li A1 Cordless drill:
Nominal voltage: 20 V
Idle-running speed: 1st gear: max. 400 min
-1
Idle-running speed: 2nd gear: max. 1400 min
-1
Drill chuck
clamping range: max. 13 mm
Maximum
drill diameter: Steel: 13 mm,
Wood: 30 mm
PABS 20-Li A1-1 Battery Pack:
Type: LITHIUM-ION
Cells: 5
Nominal voltage: 20 V
Capacity: 2.0 Ah
Energy content: 40 Wh
PABS 20-Li A1-2 Fast Charger:
INPUT
Nominal voltage: 220–240 V∼, 50 Hz
Power input: 70 W
OUTPUT
Nominal voltage: 20 V
Charging current 2.3 A
Charging time: approx. 60 min
Protection class: II /
Fuse: 3.15 A
Noise and vibration data:
Measured values for noise are determined in accor-
dance with EN 60745. The A-weighted noise level
of the electrical power tool are typically:
Sound pressure level: 67.1 dB(A)
Sound power level: 78.1 dB(A)
Uncertainty K: 3 dB
Introduction / General safety advice for electrical power toolsIntroduction
