commercial use. The warranty is void in
the case of commercial use.
Any other use that is not expressly permit-
ted in this instruction manual may result in
damage to the device and pose a serious
hazard to the user.
The device is intended for use by adults.
Children and people who are not familiar
with this instruction manual must not use
the device.
The operator or user is responsible for
any accidents or personal injury and/or
material damage to third parties or their
property.
General description
An illustration of the most im-
portant functional components
can be found on the front and
the back fold-out pages.
Scope of delivery
Carefully remove the device from the
packaging and check whether all the parts
listed below are present and complete:
- Petrol lawnmower
- 2x Lower bar
- Mounting accessories for the handlebar
- Grass collection box
- Cable clamp
- Spark plug wrench
- Mulch kit
- Screwdriver
- Quick guide
- Instruction manual
The supplied screwdriver can be used
as both a at-head and a Phillips-head
screwdriver. You can change the
screw variant by reinserting the han-
dle.
Overview
1 Handlebar
2 Safety bracket
3 Mounting accessories,
handlebar
4 Lower bar
5 Grass collection box
6 Impact protection
7 Tank cover
8 Filler plugs
9 Air lter box
10 Air lter (not visible)
11 Petrol pump (primer)
12 Lawn mower housing
13 Wheels
14 Machine handle
15 Exhaust guard
16 Spark plug connector
17 Spark plug (not visible)
18 Engine cover with ventilation
holes (nger protection)
19 Bowden cable
20 Cable clamp
21 Starter cable guide
22 Starter handle with starter cable
23 Allen key
24 Spark plug wrench
25 Mulch kit
26 Screwdriver
4a Phillips screw
3a Knurled nut
3b Washer
3c Screw
27 Attachment for grass
collection box
5a Carrying handle
28 Oil tank cap with dipstick
