PDSSA 20-Li A1
■ 48
│
GB
│
MT
Attaching/disconnecting the battery
pack to/from the appliance
Inserting the battery pack
♦ Push the rotation direction switch into
the middle position (lock). Allow the battery
pack
to click into the handle.
Removing the battery pack
♦ Press the release button and remove the
battery pack.
Checking the battery charge level
♦ Press the battery charge level button to
check the status of the battery (see also main
diagram).
The status/remaining charge will be shown on
the battery display LED as follows:
RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery
Use
Switching on and off
Switching on
♦ To start the appliance, press the ON/OFF
switch and keep it pressed in. The LED work
light lights up when the ON/OFF switch
is depressed lightly or fully. This allows for illumi-
nation of the work area in low lighting.
Switching off
♦ Release the ON/OFF switch to switch off the
appliance.
Setting the speed/tightening torque
♦ Press the ON/OFF switch lightly for a low
speed/tightening torque. Increasing the pressure
increases the speed/tightening torque.
■ The tightening torque depends on the selected
speed and impact duration.
CAUTION!
♦ The tightening torque actually attained must
always be checked with a torque wrench!
NOTE
►
The integrated motor brake ensures rapid
stoppage.
Changing the direction of rotation
♦ Change the direction of rotation by pressing the
rotational direction switch towards the left or
right.
Inserting the bits
♦ Insert the adapter or bit holder into the
tool holder .
♦ To do this, pull the locking sleeve backwards
and allow the adapter or bit holder to
engage.
Maintenance and cleaning
WARNING! RISK OF INJURY! Always
switch the appliance off and remove
the battery before carrying out any
work on the appliance.
The appliance is maintenance-free.
■ The appliance must always be kept clean, dry
and free from oil or grease.
■ Never allow liquids to get into the appliance.
■ Use a soft, dry cloth to clean the housing.
Never use petrol, solvents or cleansers which
can damage plastic.
■ If a lithium-ion battery is to be stored for an
extended period, the charge level should be
checked regularly. The optimum charge level is
between 50% and 80%. The optimum storage
environment is cool and dry.
NOTE
►
Replacement parts not listed (such as carbon
brushes, switch) can be ordered via our
service hotline.
IB_339111_PDSSA20-LiA1_LB5.indb 48 18.03.20 11:52
