Parkside PFBS 160 B2 User Manual

PFBS 160 B2
■ 10
│
GB
│
CY
Use
Changing/inserting the tool/collet
chuck
♦ Press the spindle lock and hold it down.
♦ Turn the tensioning nut
until the lock clicks
into place.
♦ Undo the tensioning nut
from the thread
using the combination spanner .
♦ Remove any tool which is inserted.
♦ First push the intended tool through the tension-
ing nut
before inserting it into the appropri-
ate collet chuck for the tool shaft.
♦ Press the spindle lock
and hold it down.
♦ Push the collet chuck
into the thread insert
and screw the tensioning nut tight with the
combination spanner .
Using an accessory tool with a mandrel:
♦ Use the screwdriver side of the combination
spanner
to undo and tighten the screw on
the mandrel.
♦ Insert the mandrel into the appliance as de-
scribed.
♦ Use the combination spanner
to undo the
screw on the mandrel.
♦ Insert the desired accessory tool between the
two washers on the screw.
♦ Use the combination spanner
to tighten the
screw on the mandrel.
Whet stone
♦ Do not manually grind any edges with the whet
stone
.
Fitting abrasive belts
♦ Push the abrasive belt onto the abrasive belt
mandrel from above. Tighten the screw on
the abrasive belt mandrel in order to fix the
abrasive belt .
Fitting polishing attachments
♦ Screw the polishing attachment onto the tip
of the mandrel for polishing attachments .
Switching on and off/setting speed
range
CAUTION!
■ The rotation direction can be read off the
arrow engraved on the union nut
(anti-
clockwise symbol).
Switching on/setting the speed range:
♦ Set the ON/OFF switch
to the "I" position.
♦ Set the infinitely variable speed control
to
a position between "1" and "MAX".
Switching off:
♦ Move the ON/OFF switch
to the position
"O".
