13 Opening of cleaning agent tank
14 Quick-action
water supply connector
15 Cleaning agent tank
16 Accessories holder
17 Jet tube w/ high-pressure nozzle
18 Jet tube w/ at spray nozzle
19 Rotating brush
20 Nozzle cleaning pin
21 Cleaning agent
22 Fork spanner
Functional description
The pressure washer uses high-pressure
water for cleaning.
A detergent can be added if this is re-
quired.
For the functions of the operating elements
please refer to the subsequent description.
Ensure that the safety instructions are al-
ways observed!
Scope of Delivery
Unpack the pressure washer and verify the
contents:
- Pressure washer with power supply
cable
- High-pressure hose on reel
- Cable hook
- Jet gun holder
- Quick-action
water supply connector
- Jet gun
- Jet tube w/ high-pressure nozzle
- Jet tube w/ at spray nozzle
- Rotating brush
- Nozzle cleaning pin
- 0.5 l cleaning agent
- Fork spanner
Start-up
In keeping with current regulations
a pressure washer must never be
operated off the drinking water mains
supply without a controllable back-
ow preventer. A suitable backow
preventer in conformity with EN
12729 type BA must be used.
Water that has passed through a backow
preventer is classied as undrinkable.
A backow preventer is available in spe-
cialist shops.
• Employ an ordinary garden hose for
the water intake and ensure sufcient
length.
• Use the device on a domestic water
supply or a water source with a feed
rate of at least 500l/h.
Setting up
• Slide the cable hook (5) and the jet
gun holder (11) onto the guides on the
device housing.
• Connect the high-pressure tting (jet
gun) (12) to the jet gun (1). Use the
fork spanner from the package.
• Connect the quick-action water supply
connector (14) to the unit’s water sup-
ply port (9). Always use the lter insert
(8) and clean this as required.
• Plug in and turn the jet tube with high-
pressure nozzle (17) or the jet tube
with at spray nozzle (18) or the rotat-
ing brush (19) to connect to the jet
gun (1).
