length.
• Use the device on a domestic water
supply or a water source with a feed
rate of at least 450l/h.
Setting up
1. Push the carry handle (2a) into the
square tube on the mounting frame.
The carry handle (2a) audlibly clicks
into place. Fix the carry handle (2a)
from the back using the two screws
(2b) enclosed.
2. Slide the holder for mains cable (5)
and the jet gun holder (11) onto the
guides on the device housing.
3. Connect the high-pressure tting (jet
gun) (12) to the jet gun (1). Use the
fork spanner from the package.
4. Connect the feed hose to the water
supply and allow water to escape from
the other end of the feed hose with no
bubbles, in order to expel the air from
the feed hose. Switch off the water tap.
5. Connect the supply hose to the water
connection (9) on the equipment using
the quick connector for garden hose
adapter (13). Always use the lter
insert (8) and clean this as required
(bayonet xing).
6. Plug in and turn the turbo dirt blaster
(17) or the standard Vario nozzle (18)
or the rotating wash brush (19) to con-
nect to the jet gun (1).
7. To change the jet tube (17/18) or the
rotating wash brush (19) push in the
tube or brush and turn in the opposite
direction.
Mains connection
The pressure cleaner you have acquired
is already tted with a mains plug. The
equipment is designed for connection to
an earthed wall socket with a residual
current operated device (RCD switch) at
230V~50Hz.
Only operate the pressure cleaner
after all the above points have been
observed.
1. Ensure that the pressure cleaner is
turned off by its ON / OFF switch
(10).
2. Insert the mains plug into the mains
socket
Operation
Be prepared for the recoil
force of the emitted wa-
ter jet! Ensure that you are
standing rmly and that you
are holding the gun (1) se-
curely, otherwise you could
injure yourself or other peo-
ple.
Never operate the pressure cleaner
with a closed water tap. Dry run-
ning will damage the pressure
cleaner!
1. Turn on the water tap entirely.
2. Switch on the pressure cleaner with the
ON / OFF switch (10).
Only ever switch on the pressure clean-
er once you have connected all of the
water pipes and they do not leak.
The motor switches on until the re-
quired pressure has built up. After
the pressure has built up, the motor
switches off.
3. Press the gun (1) starting lever (24).
The nozzle operates by pressure and
the motor switches back on.
Releasing the starting lever (24) causes
the equipment to switch off. The system
remains pressurised.
• The turbo dirt blaster (17) produces a
rotating water jet and is designed for
low water consumption work.
