4-20 mA Output
Lasair II Particle Counter Operations Manual Page J-3
4-20 mA Output
Lasair II particle counter (software version 1.4.0 or newer) supports 4-20 mA
output. This feature is enabled and configured from the 4-20 mA Out Setup Screen.
NOTE:
Use of this feature requires that an optional 4-20 mA board
be installed in the unit.
If a board is installed, but the 4-20 mA feature is disabled, all outputs will be set to
4 mA.
Figure J-1: 4-20 mA Output Setup Screen
