Partlow MRC 7000 - Current Output Board

65
If this option board was ordered, you will find it located in the lower right hand corner of the
instrument.
FIGURE A-4 - CURRENT OUTPUT BOARD
TB10 TB11
TB12
TB13
U1
U3
U2
U5
U4
U7
U6
U9
U8
R50 R51 R52
R53
